Research on Balance Testing of Die-Cutting Pressure Based on Pulse System

Abstract:

The equilibrium of the die-cutting pressure plays a decisive role in the die-cutting quality and the service life of a die cutter. The number and the distribution of the cutting balance knife influence the cutting pressure distribution. Using the transducer to collect vibration signal and converted into die cutting pressure qualitatively, which can comprise the balance of the cutting pressure, compared with the traditional pressure paper it has the advantages of quick, direct, etc., capable of measurement range is much larger than the pressure transducer, providing a new method for the determination of the super pressure by using acceleration transducer measuring pressure.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 245-248
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.245
• Online since: February 2013
• Authors: Jian Guo Li, Yi Ming Wang, Xiang Dong Shi, Lei Zhang
• Keywords: Balance Knife, Die-Cutting Press, Pulse Test System

References

[1] Ding yi, zhang bo. (2010). Dynamic simulation study of die-cutting machine table based on adams. Packing engineering. VOL.31. P60-62.

[2] Wang qiang. (2009).Research of the real time pressure online test system of the vertical platen die-cutting machine. Xi'an university of technology thesis. P3-7

[3] Xve chaozhi, Qi yuansheng. (2011).The mechanism analysis and experiment research about die-cutting pressure. Packing engineering. Vol.19, P39-42

[4] Qi yuansheng. (2011).Finite element analysis of die cutter frame. Packing engineering Vol32 P62-65

[5] Cyril M.harris, Allan G,piersol (2008)Harris's shock and vibration handbook. Fifth edition. Patent 21.P281-285
