A Novel Three-Phase Power Factor Correction with Digital Control

Abstract:

A new three-phase power-factor-correction (PFC) scheme is discussed using two single phase power factor correction circuit parallel connected. Two phase orthonormal voltage is produced by means of a auto transformer from a three phase input,fluctuation of neutral point by three single phase power-factor-correction circuit parallel connected is canceled,coupling interference is reduced among three phases,digitally controlled Power Factor Correction Boost Converters is adapted,input current wave sine with unity power factor suppress the secondary harmonic of input AC side is realized,voltage and low current stresses across each switch are reduced. Simulation and experimental results prove that it can achieve high power factor,low current,good capability of anti-interference and high reliability.

• Periodical: Applied Mechanics and Materials (Volumes 313-314)
• Pages: 365-369
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.313-314.365
• Online since: March 2013
• Authors: Yun Tao Yue, Zhi Hong Liu, Yan Lin
• Keywords: Digital Control, Harmonic, Power Factor Correction (PFC), Power Quality (PQ)

References

[1] Kamnarn, U.; Chunkag, V. Analysis and Design of a Modular Three-Phase AC-to-DC Converter Using CUK Rectifier Module With Nearly Unity Power Factor and Fast Dynamic Response. IEEE Transactions on industrial power electronics, 2009, 24(8):2000-2012.

DOI: 10.1109/tpel.2009.2019575

[2] Itoh, J.-I.; Ashida, I. A Novel Three-Phase PFC Rectifier Using a Harmonic Current Injection Method. IEEE Transactions on industrial power electronics, 2008, 23(2):715-722.

DOI: 10.1109/tpel.2007.915774

[3] Guozhu Chen; Smedley, K.M. Steady-State and dynamic study of one-cycle-controlled three-phase power-factor correction. IEEE Transactions on industrial electronics, 2005, 52(2):355-362.

DOI: 10.1109/tie.2005.843920

[4] P Pejovic, Z Janda. Optimal Current Programming in Three-phase High-power-factor Rectifier based on Two Boost Converters. IEEE Trans.on Power Electronics,1998,13(6):1152-1163.

DOI: 10.1109/63.728342

[5] H Mao，F C Lee，Dushan Boroyevich. Review of High-performance Three-phase Power-factor Correction Circuits. IEEE Trans.on Industrial Electronics,1997,44(4):437-446.

DOI: 10.1109/41.605616

[6] G Spiazzi，F C Lee.Implementation of Single-phase Boost Power-factor-correction Circuits in Three-phase Application. IEEE Trans.on Industrial Electronics,1997,44(3):365-371.

DOI: 10.1109/41.585834

[7] Schenk K，Cuk S A.Simple Three-phase Power Factor Correction with Improved Harmonic Distortion. IEEE Power Electronics Specialists Conference. Missouri, USA:[sn], 1997:399-405.

DOI: 10.1109/pesc.1997.616755
