Load Behavior Prediction in a Tumbling Mill

Abstract:

mportance of the SAG (Semi Autogenous Grinding) mills for the mineral complexes persuades many researchers to study the behavior of these huge equipments. Laboratory mills and the DEM (Discrete element method) software are the prevalent and reliable methods of modeling the mill behaviors. The former is very costly and the latter not only takes the much time but also needs the very advanced computers. In the present work, a method is presented to predict the charge profile and shoulder and toe positions for a case study mill. Experimental relations are manipulated to determine the en masse geometry and the kinetic relations are used to explain the ball movement on the liner in order to determine the shoulder and toe positions. Model results have very good accordance with the experimental results obtained of a laboratory mill. The model is used to predict the load behavior of a SAG mill in the Sarcheshmeh copper complex in Iran. Acceptable results due to low cost and quickness make it as an appropriate method for predicting the charge profile in that tumbling mill.

• Periodical: Applied Mechanics and Materials (Volume 315)
• Pages: 394-398
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.315.394
• Online since: April 2013
• Authors: M. Akhondizadeh, M. Fooladi Mahani, M. Rezaeizadeh, S.H. Mansouri
• Keywords: Charge Profile, Experimental Model, Mill, Theoretical Model

References

[1] H. Dong, and M.H. Moys, A technique to measure velocities of a ball moving in a tumbling mill and its applications, Minerals Engineering, Vol. 14, No. 8, pp.841-850, (2001).

DOI: 10.1016/s0892-6875(01)00086-3

[2] Nenad Djordjevic, Influence of charge size distribution on net-power draw of tumbling mill based on DEM modelling, Int. Journal of Mineral Processing, (2004).

DOI: 10.1016/j.mineng.2004.06.001

[3] J. T. Kalala, M. Bwalya, and M.H. Moys, Discrete element method (DEM) modelling of evolving mill liner profiles due to wear. Part II. Industrial case study, Int. Journal of Mineral Processing, (2005).

DOI: 10.1016/j.mineng.2005.02.010

[4] M.S. Powell A.T. McBride, A three-dimensional analysis of media motion and grinding regions in mills, international journal of minerals Engineering, (2004).

DOI: 10.1016/j.mineng.2004.06.022

[5] B. Augustine, A new approach to optimising the life and performance of worn liners in ball mills: Experimental study and DEM simulation, international journal of minerals Engineering, (2007).

[6] S. Morrell, Power draw of wet tumbling mills and its relationship to charge dynamics, Part 2: An empirical approach to modeling of mill power draw, Int. Journal of Mineral Processing, (1996).
