Investigating the Capability of Acoustic Emission Technology to Determine Slug Velocity in Gas/Water Two Phase Flow in Horizontal Pipes

Abstract:

Two phase flow is a common phenomenon that exists in the petroleum and chemical engineering industrial fields. An important feature employed to describe two phase flow is the flow regime which varies depending on the individual velocities of the components within the two-phase flow. One of these regimes, the slug regime, can create significant pressure fluctuations that compromise the integrity of the transporting structure (pipes, separators, etc). This is in addition to other unwanted effects such as flooding at the receiving end, an increase in deposits of hydrates and corrosion. Under such circumstances the detection of the slug and its associated characteristics are vitally important to the operator. This experimental study looks into the application of Acoustic Emission (AE) technology for detecting slug velocity in two phase (gas/liquid) flow. It is verified that slug velocity can be determined by using acoustic emission sensors.

• Periodical: Applied Mechanics and Materials (Volume 315)
• Pages: 545-551
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.315.545
• Online since: April 2013
• Authors: M.A. Alssayh, Shuib Husin, Abdulmajid Addali, David Mba
• Keywords: Acoustic Emission (AE), Flow Regime, Slug Velocity, Two-Phase Flow

References

[1] Taitel Y, Dukler AE. A model for predicting flow regime transitions in horizontal and near horizontal gas_liquid flow. AIChE Journal 1976; 22: 47_55.

DOI: 10.1002/aic.690220105

[2] Nydal O J, Pintus S, Andreussi P. Statistical characterization of slug flow in horizontal pipes. International Journal of Multiphase Flow 1992; 18: 439_53.

DOI: 10.1016/0301-9322(92)90027-e

[3] Emerson d R, Leonardo G J. A non-intrusive probe for bubble profile and velocity measurement in horizontal slug flows. Flow Measurement and Instrumentation 2005; 16: 229-39.

DOI: 10.1016/j.flowmeasinst.2005.03.003

[4] Gu H, Gue L. Experimental investigation of slug development on horizontal two-phase flow. Chinese Journal of Chemical Engineering 2008; 16: 171-77.

DOI: 10.1016/s1004-9541(08)60058-0

[5] Fusheng Z, Feng D. A measurement method of slug flow velocity of gas-liquid two-phase flow in horizontal pipe. Instrumentation and Measurement Technology Conf (I2MTC), IEEE (3-6 May 2010): 250 - 54.

DOI: 10.1109/imtc.2010.5488229

[6] British S. Nondestructive testing – terminology, Part 9: Terms used in acoustic emission testing 2000(BS EN 1330-9: 2000).

[7] Muravin D B. Acoustic emissions science and technology 2009; Available at: www. muravin. com. Accessed June/15.

[8] Hellier C. 2001 Handbook of Nondestructive Evaluation (New york ; London: McGraw-Hill).

[9] Holroyd T J. 2000 The Acoustic Emission & Ultrasonic Monitoring Handbook (Oxford: Coxmoor).

[10] Yen G G, Lu H. Acoustic emission data assisted process monitoring. ISA Trans 2002 Jul; 41: 273- 82.

DOI: 10.1016/s0019-0578(07)60087-1

[11] Albion K, Briens L, Briens C and Berruti F. Flow regime determination in horizontal pneumatic transport of fine powders using non-intrusive acoustic probes. Powder Technology 2007; 172: 157-66.

DOI: 10.1016/j.powtec.2006.10.040

[12] Addali A. 2010 Monitoring gas void fraction in two-phase flow with acoustic emission Cranfield University Library: Cranfield University.

[13] Shuib H, Addali A, Mba D. 2010 Observation of Acoustic Emission from Bubble Inception and Collapse Pro of The World Congress on Engineering (London, UK. 30 June - 2 July (2010).

[14] Connor T. http: /www. drtomoconnor. com/3760/3760lect03. htm. July 17, 2011; Accessed November 25, (2011).
