Experimental and Simulation Validation Methods of Local Exhaust Ventilation (LEV) in Training Facilities Building

Abstract:

LEV is a ventilation system that collects and sucks out particles such as dusts, mists, gases, vapors or fumes out of work station, so that they can’t be breathed in by occupants. There is a lot of LEV allocated and installed in order to help protecting occupants’ health but it doesn’t work properly. To overcome this issue, computational fluid dynamics (CFD) will be implemented. Past studies CFD techniques represent a very significant improvement of air ventilation systems. However, CFD is just a tool in prediction model, which can lead to inaccuracy of predicting airflow due to problems with pre-processing, solver and post-processing with parameter from actual experimental results. As of yet, it is not possible to 100% accurately simulate airflow around a body. These codes are simply models which are close to that of a real flow, but not an exact match. All of these require validation to help minimizing percentage error in CFD methodology. Several strategies are needed to boost effectiveness of LEV in terms of predicting airflow in a geometry model. The outcome of this research can be used as a benchmark or guideline for industries to help improving indoor air quality (IAQ).

• Periodical: Applied Mechanics and Materials (Volume 315)
• Pages: 997-1001
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.315.997
• Online since: April 2013
• Authors: Ng Chee Seng, Abdul Mutalib Leman, Azmahani Sadikin
• Keywords: Air Flow, Computational Fluid Dynamics (CFD), Indoor Air Quality (IAQ), Local Exhaust Ventilation (LEV), Simulation, Validation

References

[1] Croteau, G.A., Flanagan, M.E., Camp, J.E., Seixas, N.S., 2004. The efficacy of local exhaust ventilation for controlling dust exposures during concrete surface grinding. Annals of Occupational Hygiene 48, page 509 – 518.

DOI: 10.1093/annhyg/meh050

[2] Wong, N.H., Song, J., Istiadji, A.D., 2006. A study of the effectiveness of mechanical ventilation systems of a hawker center in Singapore using CFD simulations. Building and Environment 41, page 726 – 733.

DOI: 10.1016/j.buildenv.2005.03.015

[3] Lim, K., Lee, C., 2008. A numerical study on the characteristics of flow field, temperature and concentration distribution according to changing the shape of separation plate of kitchen hood system. Energy and Buildings 40, page 175 – 184.

DOI: 10.1016/j.enbuild.2007.02.028

[4] Mendez, C., San Jose, J.F., Villafruela, J.M., Castro, F., 2008. Optimization of a hospital room by means of CFD for more efficient ventilation. Energy and Buildings 40, page 849 – 854.

DOI: 10.1016/j.enbuild.2007.06.003

[5] Yan, W., Zhang, Y., Sun, Y., Li, D., 2009. Experimental and CFD study of unsteady airborne pollutant transport within an aircraft cabin mock-up. Building and Environment 44, page 34 – 43.

DOI: 10.1016/j.buildenv.2008.01.010

[6] Department of Occupational Safety and Health (DOSH) Guidelines on Occupational Safety and Health for Design, Inspection, Testing and Examination of LEV System, 2008. DOSH Handbook.
