Hydraulic Transient Prevention with Dipping Tube Hydropneumatic Tank

Abstract:

The dipping tube hydropneumatic tank is one of the most efficient equipments to prevent water hammer in water distribution and long distance transmission pipe systems. Due to its low costs and easy to maintain features, dipping tube hydropneumatic tank has many irreplaceable advantages, however it is difficult to determine the correct size and gas volume for real world engineering applications. This paper presents a robust method to solve the problems from theory and application. Based on the Method of Characteristics (MOC) equations, this paper derives the equations for modeling dipping tube hydropneumatic tanks in water distribution systems to prevent water hammer. The equations include MOC, differential orifice head loss equation, gas law, air mass, air velocity and etc. The IBMs scientific subroutine package (SSP) is applied to solve the equations by deriving to the form of X=f (X). The method has been integrated into HAMMER. This paper also presents an example to illustrate the methods of determining the tank size, and the comparison results with sealed hydropneumatic tank and surge tank equipment.

• Periodical: Applied Mechanics and Materials (Volumes 316-317)
• Pages: 762-765
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.316-317.762
• Online since: April 2013
• Authors: Rong He Wang, Zhi Xun Wang, Feng Zhang, Ji Long Sun, Xiao Xue Wang, Jing Luo, Hai Bo Yang
• Keywords: Hammer, Hydropneumatic Tank, MOC, Pipe Burst, Water Distribution

References

[1] N J Wade, "A natural history of vision", Cambridge, MA, MIT Press,1998.

[2] Joukowski, N. E., "Memoirs of the Imperial Academy Society of St. Petersburg", Proc. Amer. Water Works Assoc. 24, 1898, p.41–424.

[3] Chaudhry, M. H., "Applied Hydraulic Transients", Van Nostrand Reinhold, New York. 1987.

[4] Streeter, V. L. and Wylie, E. B., Hydraulic Transients, New York ,McGraw-Hill,1967.

[5] Wylie, E. B., Streeter, V. L., and Suo, Lisheng, "Fluid Transient in Systems", Prentice-Hall, Englewood Cliffs,1993.

[6] AMTROL, Inc., "Design factors, application and sizing procedures for EXTROL hydro-pneumatic compression tanks in low-temperature hot water heating systems", AMTROL, Inc. 1977, Reprinted October (2003)

[7] Haestad Methods Water Solutions, "Bentley HAMMER V8i SS3 User's Guide", Bentley Institute Press, 2011.

[8] R. Scott Smith, P.E., 2005, "Simulation of Hydropneumatic Tanks in Computer Pipe Network Models", J. Hydr. Eng. Vol. 131, Issue 10, pp.909-911

DOI: 10.1061/(asce)0733-9429(2005)131:10(909)

[9] Wu, Z. Y., Wang, R. H., Walski, Thomas M., "Extended Global-Gradient Algorithm for Pressure-Dependent Water Distribution Analysis", J. Water Resour. Plann. Manage., 135(1), 2009, pp.13-22.

DOI: 10.1061/(asce)0733-9496(2009)135:1(13)

[10] Zhu, X.K. and L. Brian, "Theoretical and numerical predictions of burst pressure of pipelines". Journal of pressure vessel technology-transactions of the asme, 2007. 129(4): pp.644-652.

DOI: 10.1115/1.2767352
