Design of Universal Signal Processing Machine Based on Multiple DSP

Abstract:

With the development and application of technique on high speed digital signal processing, wide bandwidth processing, high-speed data exchanging and flexible interlink structure have been the developing trend of modern high performance signal processing machine. In this paper, one universal signal processing machine is designed based on six pieces of ADSP-TS201 TigerSHARC processors, which owns good characteristics such as: large memory, excellent processing and data-exchanging performance, reconstitution, good expansibility. This signal processing machine adopts 64Bit, 66MHz CPCI bus standard and supports the function of extending processing performance by interlinking multiple boards. The high-speed data-exchanging is realized with multiple channel optical fiber. Furthermore, it owns board-level BIT function.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 1241-1244
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.1241
• Online since: June 2013
• Authors: Yang Jian, Yu Hao Liu, Xi Jing Zhao, Hao Ming Chen
• Keywords: Field-Programmable Gate Array (FPGA), High Speed Circuit, Multiple DSP, Signal Processing Machine

References

[1] Tang Jun. Next Generation High Speed Real-time Radar Signal Processing System. IEEE International Radar Conference (2000)

DOI: 10.1109/radar.2000.851910

[2] Analog Devices Inc. ADSP-TS201 TigerSHARC Processor Hardware Reference(Revision 1.1). Analog Devices Inc. (2004)

[3] Xilinx Inc. Virtex-5 Family Overview LX, LXT and SXT Platforms (DS100 v3.1). Xilinx Inc, May 23,2007.

[4] Xilinx Inc. Virtex-5 Rocket GTP Transceiver User Guide (UG196 v1.3). Xilinx Devices Inc, May 25,2007.

[5] Zhou runjing, Jing xiaosong, Liu hongfei. Mentor WG high speed circuit board design. Publishing House of Electronics Industry (2006)

[6] Zhang haifeng, etc. HyperLynx simulation and PCB design[M], Publishing House of Machine Industry (2005)
