Novel Composite Right/Left-Handed Transmission Lines and their Applications in Infinite Wavelength Resonant Antennas

Abstract:

In this paper, two fractal-based composite right/left-handed (CRLH) transmission lines (TLs) are proposed, and their applications in infinite wavelength resonant (IWR) antennas are investigated. In order to impose CRLH properties on the TLs, both the symmetric and asymmetric unit-cells include a gap for series capacitance and Peano-fractal curves for shunt inductance. The circuit parameters analysis shows that the proposed TLs can be used to design miniaturized IWR antennas with extended bandwidth. Then, two fractal-based IWR antennas are designed and fabricated. The measured results show that the fabricated antennas have advantages in terms of small size and wide bandwidth over the reported IWR antennas.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 352-356
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.352
• Online since: June 2013
• Authors: Lin Geng, Guang Ming Wang, Ya Wei Wang
• Keywords: Composite Right/Left-Handed Transmission Line, Infinite Wavelength Resonant Antenna, Metamaterial, Peano-Fractal Curve

References

[1] CHRISTOPHE, C., TATSUO, I. Electromagnetic Metamaterials: Transmission Line Theory and Microwave Applications. Hoboken-Piscataway: Wiley-IEEE Press, 2005.

[2] HIDEO, I., PETER, S., H. Left-handed dipole antennas and their implementations. IEEE Transactions on Antennas and Propagation, 2007, vol. 55, no. 5, pp.1246-1253.

DOI: 10.1109/tap.2007.895568

[3] SUNGJOON, L., CHRISTOPHE, C., TATSUO, I. Metamaterial-based electronically controlled transmission-line structure as a novel leaky-wave antenna with tunable radiation angle and beamwidth. IEEE Transactions on Microwave Theory and Techniques, 2004, vol. 52, no. 12, pp.2678-2690.

DOI: 10.1109/tmtt.2004.838302

[4] TAKAOKI, I., KUNIO, S., TORU, M., NOBUYOSHI, K., HIROSHI, H. Beam-scanning performance of leaky-wave slot-array antenna on variable stub-loaded left-handed waveguide. IEEE Transactions on Antennas and Propagation, 2008, vol. 56, no. 12, pp.3611-3618.

DOI: 10.1109/aps.2007.4396875

[5] YUANDAN, D., TATSUO, I. Miniaturized substrate integrated waveguide slot antennas based on negative order resonance. IEEE Transactions on Antennas and Propagation, 2010, vol. 58, no. 12, pp.3856-3864.

DOI: 10.1109/tap.2010.2078449

[6] ANTHONY, L., CHRISTOPHE, C., TATSUO, I. Composite right/left-handed transmission line metamaterials. IEEE Microwave Magazine, 2004, vol. 5, no. 3, pp.34-50.

DOI: 10.1109/mmw.2004.1337766

[7] ANTHONY, L., KEVIN M. K. H., L., TATSUO, I. Inifinite wavelength resonant antennas with monopolar radiation pattern based on periodic structures. IEEE Transactions on Antennas and Propagation, 2007, vol. 55, no. 3, pp.868-876.

DOI: 10.1109/tap.2007.891845

[8] JIA-XIAO, N. Dual-band dual-mode patch antenna based on resonant-type metamaterial transmission line. IET Electronics Letters, 2010, vol. 46, no. 4, pp.266-267.

DOI: 10.1049/el.2010.3142
