Design of Collection and Conditioning Circuit for a High Precision System of Photoelectric Velocity Measurement

Abstract:

In order to meet the requirements of high-speed projectile velocity measurement, design of a high-precision projectile velocity measurement device. Device adopts laser light source as detection target surface, receiving part adopts silicon cell array for photoelectric conversion. Silicon cell array using seamless splicing technology, eliminate the test blind spot. Design the sensitivity adjustable photoelectric conversion circuit, can effectively adjust the sensitivity of each pixel of the silicon photocell, effectively resolve the pixels sensitivity difference, reduce the jump poor in test, improve the projectile velocity measurement precision.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 647-651
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.647
• Online since: June 2013
• Authors: Chun Lin Yi, Yun Fei Jia, Wang Li, Yong Shun Bai
• Keywords: Photoelectric Conversion, Photoelectric Velocity Measurement, Projectile Velocity, Silicon Photocell

References

[1] MENG Qingjie XIE Haizhong DONG Xurong. Study on the Method of Velocity Determination Using GPS[J]. Journal of Institute of Command and Technology,2002.13(1):70~73.

[2] Jiang Haiwei. Development of measurement system of coordinates of the point of impact Based on the parallel light. Nanjing University of Science and Technology,(2008)

[3] Li Xiangyin Yao Yumin. Technology and applications of laser theory. Harbin industrial university press.(2004)
