Synthesis of Parallel Manipulator with Single DOF

Abstract:

This paper proposed a new manipulator design concept which leads to a single DOF system. The system composed of a moving platform and several supporting legs. It can execute the tasks of 3D body guidance or path generation and thus replace expensive manipulators with high DOF in some conditions. There are mainly two steps in designing this manipulator. The first step is type synthesis to determine the number and types of legs. Dimensional synthesis is then executed based on the movement requirements and geometrical constraints. In this study the reduction of the DOF is also analyzed for various legs added between the moving platform and the ground. A numerical example of executing 3D body guidance is given to verify the proposed new concept.

• Periodical: Applied Mechanics and Materials (Volume 330)
• Pages: 639-643
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.330.639
• Online since: June 2013
• Authors: Chung Huang Yu, Wen Yeuan Chung
• Keywords: Body Guidance, Parallel Manipulator, Pose, Supporting Leg

References

[1] R. Beyer: Kinematic Synthesis of Mechanism, Chapman & Hall (1963).

[2] C-H. Chiang: Kinematics of Spherical Mechanisms. Cambridge University (1988).

[3] K-H. Hunt: Kinematic Geometry of Mechanisms. Oxford University (1978).

[4] D-C. Tao: Applied Linkage Synthesis. Addison-Wesley (1964).

[5] C-S. Suh and C-W. Radcliffe: Kinematics and Mechanisms Design. John Wiley & Sons (1978).

[6] K. Russell and J. Shen: "Planar Four-Bar Motion and Path Generation with Order and Branching Conditions", Journal of Advanced Mechanical Design, Systems, and Manufacturing, Vol. 5, No. 4, pp.264-273 (2011).

DOI: 10.1299/jamdsm.5.264

[7] M. Comsit and I. Visa: Design of the linkages type tracking mechanisms of the solar energy conversion systems by using multi body systems method. 12th IFToMM world congress, A582, 2007.

[8] K. Russell, W. T. Lee and R. S. Sodhi: On the application of CAD technology for the synthesis of spatial revolute–revolute dyads. Computer-Aided Design, 39: 1075–1080 (2007).

DOI: 10.1016/j.cad.2007.07.004

[9] J-J Craig, in: Introduction to Robotics, 3rd . Prentice Hall (2005).

[10] L-W. Tsai, in: Robot Analysis. John Wiley & Sons (1999)

[11] D. Stewart: A platform with six degrees of freedom. Proc. Inst. Mech. Eng., 180: 371-386 (1963).

[12] J. Gallardo-Alvarado, J.M. Rico-Martinez and G. Alici: Kinematics and singularity analyses of a 4-dof parallel manipulator using screw theory. Mechanism and Machine Theory, 41:1048-1061 (2006).

DOI: 10.1016/j.mechmachtheory.2005.10.012

[13] M-A. Laribi, L. Romdhane and S. Zeghloul: Analysis and dimensional synthesis of the DELTA robot for a prescribed workspace. Mechanism and Machine Theory, 42:859-870 (2007).

DOI: 10.1016/j.mechmachtheory.2006.06.012

[14] J. K. Eberharter: Synthesis of spatial parallel mechanisms with initial conditions using line geometry. Mechanism and Machine Theory, 42: 1289–1297 (2007).

DOI: 10.1016/j.mechmachtheory.2006.11.006

[15] K. H. Shirazi: Synthesis of an 8S5R mechanism in four-point rigid body guidance problem using Maple. Mechanism and Machine Theory, 43: 285–296 (2008).

DOI: 10.1016/j.mechmachtheory.2007.04.008
