Control System for Automatic Positioning the Working Device of Metamorphic Concrete Grouting Machine

Abstract:

In order to improve the automation level of the metamorphic concrete grouting machine, an automatic positioning control system was developed based on the knowledge of signal acquisition and hydraulic control technology with PLC and HMI. Angle sensors installed on the arms of the grouting machine and the grouting working device were used in this system. Firstly, users determine the reference position according to practical needs, and use the PLC to complete information collection and respective reference positions recording. Then, before the grouting starts, PLC makes a real-time detection and compares the positions of the excavator boom, arm and the grouting working device, and controls the hydraulic cylinders of the excavator sequentially to adjust the positions through electro-hydraulic proportional velocity regulating valve and solenoid control valves. This control system can realize automatic positioning.

• Periodical: Applied Mechanics and Materials (Volumes 336-338)
• Pages: 1281-1285
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.336-338.1281
• Online since: July 2013
• Authors: Tian Fu Cai, Jian Zhong Zhou, Xue Min Wu, Wei Ping Peng, Xi Yan
• Keywords: Automatic Positioning, Grouting Working Device, Metamorphic Concrete Grouting Machine, Programmable Logic Controller (PLC)

References

[1] Weiping Peng, Xiong Zhao, Zhao Liu. Study on grout permeation model of an equipment for grouting in Roller Compacted Concrete[J]. Advanced Materials Research. v 287-290, pp.2840-2843, (2011).

DOI: 10.4028/www.scientific.net/amr.287-290.2840

[2] Weiping Peng, Wu Xu, Yan Xi, Cai Tianfu. Research and application on automatic grouting and vibration machine in MC rapid construction [R]. Wuhan: Wuhan University, 2012 (In Chinese).

[3] Schneider company. Modicon M238 PLC—A software platform based on the somachine[EB/OL], http: /www. schneider-electric. com, 2010-10-16/2012-10-30 (In Chinese).

[4] Wang Zhong-wen, Shao Jun-peng, Design of Control System Of Industrial Steam Turbine Based on PLC and Touch Screen[J]. Journal of Harbin University, Vol 12, No. 6. pp.109-116, Dec. 2007 (In Chinese).

[5] Petter Falkman, Erik Helander, Mikael Andersson et al. Automatic Generation: A way of ensuring PLC and HMI standards[C]. Proceedings of 2011 IEEE 16th Conference on Emerging Technologies and Factory Automation, ETFA (2011).

DOI: 10.1109/etfa.2011.6059201

[6] Schneider company. Reference manual of unity pro programming language and structure[EB/OL], http: /www. schneider-electric. com, 2010-10-16/2012-10-30 (In Chinese).

[7] Zhihuai Xiao, Yiwen Zhang, Tianfu Cai, Weiping Peng, Zhao Liu. The automatic control system based on PLC in concrete's grouting and vibrating project[C]. 2011 2nd International Conference on Mechanic Automation and Control Engineering, MACE 2011 – Proceedings. pp.5358-5361.

DOI: 10.1109/mace.2011.5988203
