Behavior Control of an Automatic Inspection Robot for Insulators

Abstract:

This paper presents an automatic inspection robot for insulators installed on 500kV power transmission lines. In order to detect the poor insulators automatically, the robot’s behaviors are analyzed, and a behavior control model based on Finite State Machine (FSM) is established. Moreover, an exception handling method is proposed based on sensors and timers. The results of experiments in the laboratory prove that the control methods mentioned above are correct and valid. Experiments on a 500kV transmission live line show that the inspection robot can not only automatically move along the double insulator strings with variable intervals, but also reliably handle the abnormal conditions including slipping, power shortage, deadlocking, sensor abnormity, and probe loosening.

• Periodical: Applied Mechanics and Materials (Volumes 336-338)
• Pages: 1309-1314
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.336-338.1309
• Online since: July 2013
• Authors: Zhen Hui Li, Hong Guang Wang, Hong Zhi Zhang, Feng Ren Jing
• Keywords: Behavior Control, Inspection for Insulators, Robot

References

[1] Ikenaga. T, Miyamoto. T. Inspection device for bad insulator [P], JP19810080278, 1981-05-26.

[2] Weiping. L. The Charged Detection of the High Voltage Transmission Line Insulators, Power Supply, 1996, 13(2): 27-29.

[3] ByungHak. C, SeungHyun. B, JoonYoung. P, et al. Development of automatic inspection robot for live-line insulators [A], Proceedings of the IEEE International Conference on Transmission and Distribution Construction and Live Line Maintenance, ESMO. Albuquerque, NM, USA: 2006IEEE, 1-5.

DOI: 10.1109/tdcllm.2006.340743

[4] Seung-Hyun. B, Byung-Hak. C, Joon-Young. P, et al. Implementation of Control System for Insulator Cleaning Robot[A], SICE-ICASE International joint Conference 2006. Bexco, Busan, Korea. 2006ICASE, 3044-3047.

DOI: 10.1109/sice.2006.315307

[5] Joon-Young. P, Byung-Hak. C, Seung-Hyun. B. Development of Automatic Cleaning Robot for Live-line Insulators[A], Proceedings of the IEEE International Conference on Transmission and Distribution Construction and Live Line Maintenance, ESMO. Albuquerque, NM, USA: 2006IEEE, 1-7.

DOI: 10.1109/tdcllm.2006.340726

[6] Hongguang. W, Yong. J, Aihua. L, el al. Research of Power Transmission Line Maintenance Robots in SIACAS[A], Proceedings of the 2010 1st International Conference on Applied robotics for the Power Industry Delta Centre-Ville Montreal, Canada, Oct. 5-7, (2010).

DOI: 10.1109/carpi.2010.5624428

[7] Jingquan. X, Tao. M. Behavior Modeling of Pet-Robot Based on Finite State Machine [J], Mechatronics, 2006, 6: 29-31.

[8] Hongguang. W, Yong. J, Lijin. F, el al. Gait Planning of Concave Transitions between Different Slopes for Bipedal Wall-climbing Robots[J], CAAI Transaction on Intelligent Systems, 2007, 2(4): 40-45.

[9] Shuangfei. F, Hongguang. W, Lijin. F, el al. Research on Obstacle-navigation Control of Inspection Robot for the Exttra-high Voltage Power Transmission Lines[J], Robot, 2005, 27(4): 341-345.

DOI: 10.1109/robio.2004.1521756

[10] Joon-Young. P, Jae-Kyung. L, Byung-Hak. C, et al. An Inspection Robot for Live-Line Suspension Insulator Strings in 345-kV Power Lines[J], IEEE Transactions on Power Delivery, 2012, 27(2): 632-639.

DOI: 10.1109/tpwrd.2011.2182620

[11] Sunsin. H, Ru. H, Jangmyung. L, Inspection of Insulators on High-Voltage Power Transmission Lines[J], IEEE Transactions on Power Delivery, 2009, 24(4): 2319-2327.

DOI: 10.1109/tpwrd.2009.2028534

[12] Jae-Kyung. L, Joon-Young. P, Byung-Hak. C, el al. Development of a Live-line Inspection Tool System for 154kV Power Transmission Lines[J], Journal of Electrical Engineering &Technology, 2012, 7(1): 23-33.
