The Performance Analysis of Fiber Distributed Vibration Monitoring Technology Based on φ-OTDR

Abstract:

The performance of the fiber distributed vibration monitoring technology based on the phase sensitive optical time domain reflectometer (φ-OTDR) is reseached. the principle of fiber distributed vibration monitoring of the φ-OTDR and multi-point positioning are illustrated. And this paper indicates the feasibility of realizing multi-point positioning by the φ-OTDR system, and carry on a further research on the φ-OTDR system ́s frequency response range, measuring distance, spatial resolution and other aspects. The inverse proportion relations between the frequency range and distance of the φ-OTDR system, and the relations among spatial resolution, laser pulse width, refractive index and sampling rate are illustrated.

• Periodical: Applied Mechanics and Materials (Volumes 336-338)
• Pages: 192-195
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.336-338.192
• Online since: July 2013
• Authors: Ji Qiang Wang, Yuan Liu, Mo Yu Hou, Lin Zhao, Tong Yu Liu
• Keywords: Distributed Fiber Sensing, Frequency Response Range, Positioning Accuracy, Vibration Monitoring, φ-OTDR

References

[1] Juarez J C, Maier E W, Kyoo Nam Choi, Taylor H F. Distributed Fiber-optic Intrusion Sensor System, Journal of Lightwave Technology. 2005, 23: 2081-(2087).

DOI: 10.1109/jlt.2005.849924

[2] Juarez J C, Taylor H F. Distributed Fiber Optic Intrusion Sensor System for Monitoring Long Perimeters[J]. Proc. SPIE, 2005, 5778: 692-703.

DOI: 10.1117/12.602638

[3] K N Choi and H F Taylor. Spectrally stable Er: Fiber Laser for Application in Phase-sensitive Optical Time-domain Reflectometry. IEEE Photon. Technol. Lett., 2003, 15(3): 386–389.

DOI: 10.1109/lpt.2003.807905

[4] Liang Kezhen, Pan Zhengqing, Zhou Jun, etc. Multi-Parameter Vibration Detection System Based on Phase Sensitive Optical Time Domain Reflectometer[J]. Chinese Journal of Lasers, 2012, 39(8): 119-123.

DOI: 10.3788/cjl201239.0805004

[5] Xie K L, Rao Y J, Ran Z L. Distributed Optical Fiber Sensing System based of Rayleigh Scattering Light φ-OTDR Using Single-mode Fiber Laser with High Power and Narrow Linewidth[J]. Acta Optica Sinica, 2008, 28 (3): 569-572.

DOI: 10.3788/aos20082803.0569

[6] Mu Libo, Wu Yuefeng, Yao Jian. Study on Multiple-point Localization Problem of Distributed Fiber-optic Vibration-sensing Systems[J]. Transducer and Microsystem Technologies, 2010, 29(6): 42-49.
