Advances in Test Techniques Based on Multifunctional Sting Support System for 8m×6m Wind Tunnel

Abstract:

Multifunctional sting support system at high angle of attack is the main way of support for aircraft test in 8m×6m wind tunnel. In recent five years, a series of supporting facility has been developed to improve test efficiency and enhance the finer testing and measuring capability. New developed vibration suppression system can not only enlarge the maximum weight-bearing of the support mechanism, but also reduced the vibratory frequency of a model. Power (motor) control system was modified to adapt to the requirement of 0.2% precision. TG1801 balances were designed and manufactured with high precision and good stiffness. A remote control unit has been applied for a specific aircraft test as model facility to reduce labor intensity and raise test efficiency. Aircraft test efficiency in 8m×6m wind tunnel has been increased gradually and data accuracy reaches the advanced international level through these improvements.

• Periodical: Applied Mechanics and Materials (Volumes 336-338)
• Pages: 880-884
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.336-338.880
• Online since: July 2013
• Authors: Li Tao Fan, Xue Feng Duan, Wei Xue
• Keywords: Continuous Scan Technique, Dynamic Pressure System Improvement, High Load Strain Gage Sting Balance, Remote Control Unit, Sting Support System at High Angle of Attack, Vibration Suppression Equipment

References

[1] Sun Haisheng. The development of high angle of attack test equipment in the 8m ×6m low speed wind tunnel[J]. Journal of Experiments in Fluid Mechanics, 2009, 23(1): 70-73.

[2] Liang Jian, Zhang Weiguo, Wang Xunnian, etc. Development for restraining oscillation device of the UAV model in the 4m ×3m wind tunnel[J]. Journal of Experiments in Fluid Mechanics, 2007, 21(4): 65-69.

[3] Wang Hui. 8m×6m wind tunnel dynamic pressure application technique research conclusion[R]. Mianyang, Sichuan: China Aerodynamics Research and Development Center, (2010).

[4] Tang Qiaoqiao. Development of continuous scan technique based on main support equipment in 8m×6m wind tunnel[C]. Equipment Management Conference, Mianyang, Sichuan, (2011).

[5] Li Jinxue. Demonstration on remote control unit development in low speed wind tunnel[R]. Mianyang, Sichuan: China Aerodynamics Research and Development Center, (2010).
