Realization of a ZVS Inverting Spot Welding Power Supply

Abstract:

In this paper it constructs a phase shift to control zero-voltage-switching of high frequency inverter spot welding power supply topology structure. Through testing the former vice edge current, the system realizes the closed loop control. In this paper, it shows the working condition of main circuit modal. The experimental results proved the advantages of the topological structure.
