Design and Realization of Solar Energy Maximum Power Point Automatic Tracking System

Abstract:

Aiming at the low generating efficiency of the current solar energy generating system, solar energy maximum power point tracking control system based on STC89C52 is designed and made. The photoelectric detection and tracking is adopted as the control mode in the system. By using stepping motor as driving mechanism, comprehensive trace of the sun is realized by controlling the movement of tracking mechanism in the horizontal and pitching directions. Based on this, real-time detection of wind velocity and change of wind direction is realized by wind velocity and direction transducer which is equipped on the tracking mechanism, which makes the system automatically avoid the typhoon above level 8 to weaken the damage to panel by the storm. The experiment results of model machine indicate that the system has reliable performance which can satisfy the need of auto-solar track, it can also make the panel orient towards east again after darkness to realize daily circular run and it is of relatively high practical value.

• Periodical: Applied Mechanics and Materials (Volume 339)
• Pages: 533-538
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.339.533
• Online since: July 2013
• Authors: Gang Wang
• Keywords: Automatic Tracking, Avoidance, Solar Energy, STC89C52

References

[1] Ding Wei: Research and Implementation of automatic tracking control system of solar power generation(Nanjing University of Aeronautics and Astronautics Publications, Jiang Su2010).

[2] Reda I,Andreas A: Solar position algorithm for solar radiation applications. Solar Energy. Vol.76(5)( 2004), pp.577-589

DOI: 10.1016/j.solener.2003.12.003

[3] Zhang Dongyu: Single-dimension dragging and double-dimensions tracing intelligent solar tracking system.Control & Automation.Vol.22(16) (2006), pp.31-35

[4] Xiang Ping,Bi Yuqing,Cheng Jianmin: Design of sun tracking control system based on ARM. Computer Measurement & Control. Vol.17(6)(2009) , pp.1102-1105

[5] Geng Xin,Liu Zhongda: Design of intelligent automatic sun tracking system based on PLC .Industrial Instrumentation & Automation. Vol.13(3)(2010), pp.30-33

[6] Wang Bin,Zhang Xun: Automatic real-time solar tracking system. Astronomical Research & Technology. Vol.8(1)(2011), pp.52-57

[7] Roth P,Georgiev A: Design and construction of a system for sun tracking. Renewable Energy. Vol.29 (3)(2004), pp.393-402

DOI: 10.1016/s0960-1481(03)00196-4
