Simulation of Pumping Unit Based on Simulink

Abstract:

To study pumping unit of operating state in practical work, permanent magnet synchronous motor of direct torque control was used to model and simulate based on Matlab/Simulink software, and analyzed the waveforms change under normal operation and intermissive pumping. The results indicate that permanent magnet synchronous motor can operate smoothly under low speed and high torque condition, and can transit smoothly with different torque and acceleration. The proposed simulation system can achieve stable control, and its effectiveness is confirmed experimentally. Results of simulation analysis have some certain practical value for pumping unit driven by permanent magnet synchronous motor of direct torque control.

• Periodical: Applied Mechanics and Materials (Volume 340)
• Pages: 852-856
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.340.852
• Online since: July 2013
• Authors: Zi Kuan Zhang, Lin He, Li Yang
• Keywords: DTC, PMSM, Pumping Unit, Simulink

References

[1] Matins C A, Roboam X, Meynard T A, et al. Switching Frequency Imposition and Ripple Reduction in DTC Drives by Using a Multilevel Convert, J. IEEE Transactions on Power Electronics, vol17, pp.286-297, (2002).

DOI: 10.1109/63.988948

[2] Rahman MF, Zhong L, Lim KW, Analysis of direct torque control in permanent magnet synchronous motor drive, IEEE Trans Power Electron, 12(3): 526-8, (1997).

DOI: 10.1109/63.575680

[3] Luukko J, Pyrhonen J, Selection of the flux linkage reference in direct torque controlled permanent magnet synchronous motor drive, Adv Motion Control 5th Int Workshop 198-203, (1998).

DOI: 10.1109/amc.1998.743536

[4] Zhong L, Rahman M F, Analysis of direct torque control in permanent magnet drives, J. IEEE Transactions on Power Electronics, 12(3): 528-535, (1997).

DOI: 10.1109/63.575680

[5] Corley M J, Lorenz R D, Rotor Position and Velocity Estimation for a Permanent Magnet Synchronous Machine at Standstill and High Speeds, J. Thirty-first IAS Annual Meeting, IAS'96. Conference Record of the 1996 IEEE, vol1, pp.36-41, (1996).

DOI: 10.1109/ias.1996.556994

[6] M. K. Sahu, B. P. Panigrahi, A. K. Panda, An utility friendly direct torque control technique of three phase induction motor with two-level inverter using 180 degree conduction mode, International Journal of Engineering Science and Technology, Vol. 3, No. 5, pp.4120-4130, (2011).

[7] Y. Zhang, J. Zhu, Z. Zhao, W. Xu, D. G. Dorrell, An improved direct torque control for three-level inverter-fed induction motor sensorless drive, IEEE Transactions on Power Electronics, Vol. 27, No. 3, pp.1502-1513, (2012).

DOI: 10.1109/tpel.2010.2043543

[8] Suresh. Mikkili, A. K. Panda, SHAF for mitigation of current harmonics using p-q method with PI and fuzzy controllers, Engineering Technology & Applied Science Research, Vol. 1, No. 4, pp.98-104, (2011).

DOI: 10.48084/etasr.44
