Load Model of Scroll Wrap for Calculation of Bending Fatigue Strength

Abstract:

For calculation of bending fatigue strength of scroll wraps, the pressure loads and temperatures in compression chambers based on general profile theory are analyzed, and a load model including the pressure loads the temperatures is proposed. For the scroll wraps, their load model for bending fatigue strength includes the pressure loads and the temperatures. Their pressure loads can be simplified on the mid-areas and its temperatures are equal to the temperatures of the mid-areas. The pressure loads are of π normal angle region inner pressure load which have an interval of π normal angle, the number of regions of pressure load is equal to the number of scroll compression chamber pairs. The discharge angle has significant effect on bending fatigue strength of scroll wraps and the stability of scroll compressor.

• Periodical: Applied Mechanics and Materials (Volumes 341-342)
• Pages: 496-500
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.341-342.496
• Online since: July 2013
• Authors: Hua Zhang
• Keywords: Bending Endurance Strength, Load Model, Scroll Compressor, Scroll Wrap

References

[1] Qiang Jianguo. Mechanism and Machine Theory. 1, 45 (2010).

[2] Qiang Jianguo. ASME Journal of Fluids Engineering. 2, 132 (2010).

[3] Yu Chen, Nils P. Halm, Eckhard A. Groll, James E. Braun. International Journal of Refrigeration. 6, 25 (2002).

[4] Eckhard A. Groll, Editor. Scroll Compressor Analytical Model. Proceedings of the International Refrigeration and Air Conditioning Conference, (1986) July 14-17; Pudue, USA.

[5] Kitae Hang, Sangkwon Jeong. International Journal of Refrigeration. 5, 29 (2006).

[6] Kim Tiow Ooi, Jiang Zhu. International Journal of Sciences. 7, 43 (2004).

[7] Chiachinl Lin, Yuchoung Chang, Kuny Liang, Chinghua Hung. Applied Thermal Engineering. 11-12, 25 (2005).

[8] Yongzhang YU, Zhaolin GU, Editors. FEM Model and Analysis of the Orbiting Scroll. Proceedings of the International Compressor Technique Conference, (1997) May 8-10; Chengdu, China.

[9] Eckhard A. Groll, Editor. Determination of Scroll Wrap Contact Stress Using the Boundary Element Method. Proceedings of the International Refrigeration and Air Conditioning Confer ence, (1992) July 14-17; Pudue, USA.

[10] Qiang, J.G., Ma, X., Liu, Z.Q.,. Load model for involute scroll teeth based on tooth root bending fatigue strength. J. Eng. Therm. Energy Power 22(6), 615-619 (2007).
