Research on Multi-Cup Uniform Flow Gravity Sedimentation Single Well Injection-Production Technique

Abstract:

When the oilfield enters the hing water cut stage, the mining faces the problem that the oil-gas gathering system energy consumption reduction needs to decrease produced water and water injection. This paper proposes a novel multi-cup uniform flow gravity sedimentation single well injection-production technique. The downhole oil-water separator separates oil from water. The separated water is directly reinjected into the injection layer. Higher oil content of oil-water mixture is lifted up to the ground. The water injection and oil production in the production wellbore are simultaneous. This paper also designs a crown-like sedimentation cup structure. The experiment shows that the optimum structure of crown oil-water separator is cylindrical with 30 inclination, 12 edges and one partition baord on the tip at the bottom of corrugated shape. Produced liquid contains water 95 percent; efficiency can be increased more than three times by using multi-cup uniform flow gravity sedimentation separator.

• Periodical: Applied Mechanics and Materials (Volumes 341-342)
• Pages: 534-539
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.341-342.534
• Online since: July 2013
• Authors: Guo Xing Zheng
• Keywords: Sedimentation Cup, Single well Injection Production, Water Content, Water-Oil Separator

References

[1] Cui Chuan-zhi, Zhang Ji-qing, Yang Yong, Wang Jian, Tian Bin, Optimization Research on Production and Injection Rate Proration for Typical Well Groups of Fault Block Reservoir in Extra High Water Cut Stage, Science Technology and Engineering, vol. 13, pp.687-699, January (2013).

[2] An Wei-yu, Interference mechanism of multilayer heterogenous reservoir in high water-cut stage, Journal of Northeast Petroleum University, vol. 36, pp.76-82, October (2012).

[3] Han Hong-sheng, Li Xiao-feng, Lv Ning, Zhan Shu-hong, Study of Effect of Sink Sand on Oil-water Separation in Gather and Flow Pattern Oil-water Separator, Oil Field Equipment, vol. 41, pp.51-54, February (2012).

[4] Yang Shu-ren, Xie Wei, Optimization design of oil-water separator for injection-production in the same well, Special Oil & Gas Reservoirs, vol. 18, pp.106-108, December (2011).

[5] CHENG Xin-ping, LIU Min, Development and Application of Single Well Integral Injection/Production Technique, Oil Field Equipment, vol. 39, pp.82-87, October (2010).
