Design of Condenser Rubber Ball Cleaning Counting System Based on CPLD

Abstract:

The working condition of the condenser in power plant is an important factor that affects the economic operation of the power plant. Rubber ball cleaning is a main method to deal with the condenser fouling. The thesis, dealing with the problem of counting errors of rubber ball in the process of condenser cleaning, based on CPLD(Complex Programmable Logic Device) technology, designs a programme have rubber balls checking and counting automatically. The program takes use of the controlled laser sensors to count the number of rubber balls in every single pipe and the parallel processing capacity of CPLD,and have the number of different pipes counted and shown. Experiments have proved its constancy and accuracy.

• Periodical: Applied Mechanics and Materials (Volumes 341-342)
• Pages: 684-689
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.341-342.684
• Online since: July 2013
• Authors: Xiao Wei Han, Yi Zhen Sun, Xiao Xia Liu, Chang Tong Li
• Keywords: Complex Programmable Logic Device (CPLD), Condenser, Laser Sensor, Rubber Ball Counting

References

[1] TAPROGGE Gesellschaft mbH. Ball Effectiveness Monitor BEM, http: /halmel. com. au/halmel/Brochures/Taprogge%20New/Ball%20effectiveness%20monitor%20BEM. pdf.

[2] TAPROGGE Gesellschaft mbH. Ball Recirculation Monitor BRM, http: /halmel. com. au/halmel/Brochures /Taprogge%20New/Ball%20Recirculation%20monitor%20BRM. pdf.

[3] S. Kaneko et al., Patent No. 3302897, Heat Exchanger Tube Cleaning System and Operation Method, registration date; April 26, 2002, in Japanese.

[4] Akihito Suzuki, Kenchu Seki, Dr. Eng. Takeo Takei. High-performance Condenser Tube Cleaning System－Featuring Advanced Ball Collecting Technology, Hitachi Review Vol. 54 , p.3, (2005).

[5] F.Y. Wang, Q. R Tao, The Design of Counter for Rubber Ball Detection Based on AT89C2051 Singlechip, MICROCOMPUTER INFORMATION, Vol. 24, pp.124-125, (2008).

[6] C. Cao, X.Q. Wu, Design of AT89C2051-based Rubber Ball Statistics Device of Condenser, PROCESS AUTOMATION INSTRUMENTATION, Vol. 30, pp.14-16, (2009).

[7] W.P. Zheng, W. Sun, Q.Y. Zhao, Y.L. Liu, Z.C. Li, The Study and Transformation of the Condenser Rubber Ball Cleaning and Automatic Detecting Device, MODERN BUSINESS TRADE INDUSTRY, Vol. 22 , pp.311-312, (2010).

[8] X.F. Wang, W.P. Zheng, Z. Li, Condenser Rubber Ball Cleaning and Automatic Detecting Device, ENERGY CONSERVATION, Vol. 27, pp.29-32, (2008).

[9] H.W. Li, S.H. Yuan, FPGA/CPLD Design Based on the QuartusⅡ, CA: Beijing Electronic Industrial Publisher, (2006).

[10] Y.W. Xia, Numerical Systematic Designing Tutorial, CA: Beijing Univercity of Aeronautics and Astronautics, (2004).
