Research and Application for Two-Cylinder Electro-Hydraulic Servo Synchronous Control Technology

Abstract:

The two-cylinder drive is one of many commonly used mechanical drive forms. Its synchronous control accuracy determines the movement accuracy of the working machinery. The paper established the mathematical model for the two-cylinder electro-hydraulic servo synchronous drive system, and revealed that the two-cylinder horizontal electro-hydraulic synchronous drive system has the cascade form of the linear system with the nonlinear system. Taking the band sawing machine and the broaching machine as the application object, the paper analyzed their compositions and synchronization CNC systems. Aiming at the dual-cylinder drive form for the broaching machine, the IPSO-PID synchronous controller of the two-cylinder system was designed. Through the digital simulation and actual testing, the results show that the IPSO-PID synchronous controller is faster in the tracking response speed and better in the synchronization performance than the conventional PID synchronization controller.

• Periodical: Applied Mechanics and Materials (Volume 344)
• Pages: 139-144
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.344.139
• Online since: July 2013
• Authors: Guo Jin Chen, Jing Ni, Ting Ting Liu, Ming Xu, Hui Peng Chen
• Keywords: Band Sawing Machine, Broaching Machine, Electro-Hydraulic Servo, IPSO-PID, Synchronous Control

References

[1] ZHU Jie, CHEN Guo-jin, WANG Wan-qiang, Applying FPGA on Frequency Convert System of SVPWM, Mechanical & Electrical Engineering Magazine, Vol. 22, No. 4, p.22–25, (2005).

[2] CHEN Guo-jin, YAO Zhai-rong, SUN Hong, Realization of AC Motor Vector Control Based on DSP, Mechanical & Electrical Engineering Magazine, Vol. 21, No. 6, p.27–30, (2004).

[3] WANG Tao, CHEN Guo-jin, NI Jing, Design and application of electric control system on pattern drawing machine, Journal of Mechanical & Electrical Engineering, Vol. 29, No. 4, p.413–416, (2012).

[4] LI Yong-ning, YANG Hua, CHEN Guo-jin, Application of μC/OS-Ⅱ in digital welder control system, Journal of Mechanical & Electrical Engineering, Vol. 28, No. 7, p.827–830, (2011).

[5] CHEN Guo-jin, CHEN Hui-peng, CHEN Li-ping, Research on multidisciplinary modeling and robust control for electric power steering system, Advanced Materials Research, Vol. 179-180, pp.179-185, (2011).

DOI: 10.4028/www.scientific.net/amr.179-180.179

[6] CHEN Guo-jin, DENG Kai-ping, GONG You-ping, The Design and Simulation of Walking Hydraulic Transmission System of Loader HT25J, Mechanical Engineer, No. 6, p.46–49, (2012).
