The Analysis of Transient Grounding Resistance of Portable Horizontal Grid Earth Electrodes

Abstract:

Based on current situation of mobile equipments earth devices, a new type of portable horizontal grid earth electrode has been designed. With the impulse ground measurement system, different number of earth electrodes responses to double exponential pulse current have been tested on cement grounds. Impulse waves of voltage and current have been gotten by experiments, and the curve of Transient Grounding Resistance (TGR) can be calculated. The analysis of discharging capacity of horizontal grid earth electrodes in time domain has great significance in the design of mobile equipments earth devices.

• Periodical: Applied Mechanics and Materials (Volumes 347-350)
• Pages: 1753-1757
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.347-350.1753
• Online since: August 2013
• Authors: Xin Bo Qu, Bi Hua Zhou, Ning Sheng Cao, Ya Peng Fu, Xiao Gang Huang
• Keywords: Horizontal Grid Earth Electrode, Portable, Transient Grounding Resistance

References

[1] Zhou Bihua, Chen Bin, Shi Lihua. Electromagnetic Pulse and Engineering Protection [M]. Beijing：National Defence Industrial Press, (2003).

[2] Chen Jiabin. The Earth Technique and Earth-termination System. [M]. China Power Press, Apr. (2009).

[3] GB 50689-2011 Code for Design of Lightning Protection and Earthing Engineering for Telecommunication Bureaus(Stations) (2012) [S]. Beijing：Chinese Plan Publishing House. Feb. (2012).

[4] Fan Mian. Development of Tower Grounding Device's Impulse Ground Impedance Measurement System. [D], Xihua University, May (2008).

[5] JI Yafei, Yangyu, Zhou Jun. Fast Algorithm for Calculating the Transient Current Distribution of a Lightning Protection System [J], High Voltage Engineering, Oct. (2009).

[6] Yang Huina. The Determination of the Earth Model and the Simulating Calculation of the Earth Grid's Transient Character [D]. Beijing：Tshinghua University, (2003).

[7] Zhang Bo, Cui Xiang, Zhao Zhibin, etc. Analysis of the Complex Grounding Grids in Frequency Domain Considering Mutual Inductances. [J]. Proceedings of the CSEE, 2003, 23(4): 77-80, 118.

[8] He Hongbing, Zhou Bihua, Yu Tongbin. Analysis of Transient Grounding Resistance Under Pulsed Discharging Current [C]. Proc Asia-Pasific conf on Environmental Electromagnetics, Hangzhou, China, 2003, 554~557.

DOI: 10.1109/ceem.2003.238411

[9] Chen Jiaqing, Zhou Bihua, He Hongbing. The Analysis of Transient Grounding Resistance of a Number of Shunt-wound Vertical Grounding Rods in Time Domain [J]. The Lightning Protection and Standardization, 2005. 2: 11~14.

DOI: 10.1109/mape.2005.1617961
