Fault Feature Extraction of High-Speed Automaton Based on Motion Morphology Decomposition

Abstract:

In order to obtain the characteristic parameters reflecting fault state of high-speed automaton (HSA), the fault feature extraction method based on motion morphology decomposition and wavelet packet transform (WPT) was presented. According to the movement law of the automaton, the vibration signal generated in three bursts of fire was decomposed into three separate signals, then the response signal in each shooting is a separate signal. Then using WPT to respectively extract wavelet packet energy from three separate signals as the fault characteristic parameters of HSA. By the example, the results show that the extracted fault features can well reflect the working conditions of automaton. Thus the proposed method could be used to extract the fault feature of automaton for monitoring the condition and diagnosing the fault of automaton.

• Periodical: Applied Mechanics and Materials (Volumes 347-350)
• Pages: 224-227
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.347-350.224
• Online since: August 2013
• Authors: Ai Yu Wang, Hong Xia Pan, Hui Ling Liu
• Keywords: Feature Extraction, High-Speed Automaton, Motion Morphology Decomposition, Vibration Signal

References

[1] Zeng Xianwei, Zhao Weiming, Sheng Juqin: Corresponding relationships between nodes of decomposition tree of wavelet packet and frequency bands of signal subspace. Acta Seismologica Sinica, 2008; 30(1): 90-96.

DOI: 10.1007/s11589-008-0091-x

[2] Hua Hanbing: Application and Research of De-noising of Vibration Signal Based On Wavelet Packet. Noise and Vibration Control, 2007(6): 19-21.

[3] Cao Jianjun, Zhang Peilin, Zhang Yingtang, et al: Feature Extraction of An Engine Cylinder Head Vibration Signal Based on Lifting Wavelet Packet Transformation. Journal of Vibration and Shock, 2008; 27(2), pp.34-37.

[4] Zhao Pengliang, Xi Zemin, Xiao Huan: Feature Extraction Based on Wavelet packet Transform and Modified SVD. Ship Electronic Engineering, 2007; 27(4): 123-125.

[5] Zhang Wenbin, Zhou Xiaojun, Lin Yong, et al: Harmonic wavelet package method used to extract fault signal of a rotation machinery. Journal of Vibration and Shock, 2009; 28(3): 87-89.

[6] Hong Ye, Li Guohong, Cai Weiyou, et al: Fault diagnosis of hydro-generator unit vibration based on wavelet packet analysis. Engineering Journal of Wuhan University, 2002; 35(1): 65-68.

[7] Peng Wenji, Luo Xingqi: Research on Vibrant Fault Diagnosis of Hydro-turbine Generating Unit Based on Wavelet Packet Analysis and Support Vector Machine. Proceedings of the CSEE, 2006; 26(24): 164-168.
