Optimal Energy-Effective Gait for Biped Robot

Abstract:

Although peoples legs are capable of a broad range of muscle-use and gait patterns, they generally prefer just two, walking and running. A popular hypothesis regarding legged locomotion is that humans and other large animals walk and run in a manner that minimizes the metabolic energy expenditure for locomotion. Here, a mathematical model for a simple two-dimensional planar kneed walker with point feet and two bended knees is discussed. An energy-effective gait is designed by using piecewise torque method. Then, the robot model can exhibit a natural and reasonable walk on a level ground. The results can prove that the proposed optimal energy-effective gait is suitable for this kneed biped walking robot. And we also discover some walking rules maybe true through the results of optimization.

• Periodical: Applied Mechanics and Materials (Volumes 347-350)
• Pages: 839-843
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.347-350.839
• Online since: August 2013
• Authors: Li Peng Yuan, Li Ming Yuan, Hong Ying Lu
• Keywords: Biped Robot, Energy-Effective, Optimization

References

[1] A. D. Kuo, J. M. Donelan, and A. Ruina. Energetic consequences of walking like an inverted pendulum: step-to-step transitions. Exer. Sport Sci. Rev., 33: 88–97, (2005).

DOI: 10.1097/00003677-200504000-00006

[2] N. Rashevsky. Studies in the physicomathematical theory of organic form. Bull. Math. Biophysics., 6: 1–59, (1944).

[3] R. McN. Alexander. Elastic mechanisms in animal movement. Cambridge University Press, Cambridge., (1988).

[4] T.A. McMahon and G.C. Cheng. The mechanics of running: how does stiffness couple with speed? J. Biomech., 23, Suppl. 1: 65–78, (1990).

DOI: 10.1016/0021-9290(90)90042-2

[5] R. McN. Alexander. Mechanics of bipedal locomotion., volume 1, page 493504. Pergamon Press, New York, (1976).

[6] Vanessa F. Hsu Chen. Passive Dynamic Walking with Knees: A Point Foot Model. Massachusetts Institute of Technology Press, Massachusetts., (2007).

[7] F. Asano, M. Yamakita and K. Furuta. Stabilizing control of passive biped robot and its application to active walking, in Proc. 5th Int. Conf. Artif. Life and Robot., vol. 2, p.503–506, (2000).

[8] K Kaneko, F. Kanehiro, S. Kajita, H. Hirukawa, T. Kawasaki, , M. Hirata, K. Akachi, and T. Isozumi. Humanoid robot hrp-2. In Proc. of the IEEE Conf. on Robotics and Automation, pages 1083–1090, (2004).

DOI: 10.1109/robot.2004.1307969

[9] Jean-Jacques E. Slotine and Weiping Li. Applied Nonlinear Control. Prentice Hall, October (1990).

[10] Manoj Srinivasan and Andy Ruina. Computer optimization of a minimal biped model discovers walking and running. Nature Vol 439: 72-75, (2006).

DOI: 10.1038/nature04113
