Fire Resistance of Web-Slotted Cold-Formed Channel Columns with Non-Uniform Temperature Distributions

Abstract:

The fire resistant behavior of web-slotted cold-formed channel columns with non-uniform temperature distributions was investigated extensively by use of the finite element method in this article. The failure mode of the web-slotted column with non-uniform temperature distributions is very complex with the interaction of the local buckling, the distortional buckling and the global flexural buckling. The ultimate strengths of members with non-uniform temperature distributions are higher than that with uniform temperature distributions of the same highest temperature. In addition the analysis results indicate that the degradation of the material strength makes the dominating factor influencing the fire resistance of cold-formed members. The simplified approach was proposed for the practical design of web-slotted cold-formed columns at high temperatures.

• Periodical: Applied Mechanics and Materials (Volumes 353-356)
• Pages: 2313-2318
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.353-356.2313
• Online since: August 2013
• Authors: Qi Jie Ma, Pei Jun Wang, Quan Huang
• Keywords: Fire Resistant, Non-Uniform Temperature Distributions, Simplified Design Method, Web-Slotted Lipped Channel

References

[1] Kosny. J, Christian J.E. Thermal evaluation of several configurations of insulation and structural materials for some metal stud walls, Energy and Buildings 1995; 22(3): 157-163.

DOI: 10.1016/0378-7788(94)00913-5

[2] Kaitila O. Imperfection sensitivity analysis of lipped channel columns at high temperatures. Journal of Constructional Steel Research 2002; 58(3): 333-51.

DOI: 10.1016/s0143-974x(01)00060-8

[3] Lee J. Local buckling behaviour and design of cold-formed steel compression members at elevated temperatures. PhD thesis. Queens-land University of Technology, (2004).

DOI: 10.1201/9781351077309-34

[4] M.Q. Feng. Numerical and Experimental Studies of Cold-formed Thin-walled Steel Studs in Fire, PhD thesis, University of Manchester, (2003).

[5] Ranby A. Structural fire design of thin-walled steel sections. Journal of Constructional Steel Research 1998; 46(1-3): 303-4.

DOI: 10.1016/s0143-974x(98)00118-7

[6] Thanuja Ranawaka, Mahen Mahendran. Distortional buckling tests of cold-formed steel compression members at elevated temperatures. Journal of Constructional Steel Research 2009; 65(2): 249-259.

DOI: 10.1016/j.jcsr.2008.09.002

[7] Thanuja Ranawaka, Mahen Mahendran. Numerical modeling of light gauge cold-formed steel compression members subjected to distortional buckling at elevated temperatures. Thin-Walled Structures 2010; 48(4-5): 334-344.

DOI: 10.1016/j.tws.2009.11.004

[8] Chen J, Jin WL. Behavior of high strength cold-formed steel columns under elevated temperatures. Engineering Mechanics 2009; 26(12): 167-174.

[9] B. Salhab, Behavior of Cold-formed Thin-walled Steel Studs with Perforated Web at Ambient Temperature and in fire, PhD thesis, University of Manchester, (2007).

[10] AS/NZS 4600. Australian/New Zealand Standard. Cold-formed steel structures, Standards Australia, Sydney, (2005).

[11] Hőglund, T. and Burstrand, H. Slotted steel studs to reduce thermal bridges in insulated walls. Thin-Walled Structures, 1998; 32(1-3): 81-109.

DOI: 10.1016/s0263-8231(98)00028-7

[12] Elhajj, N. R. Development of cost-effective, energy-efficient steel framing. Final Report, AISI/DOE Technology Roadmap Program, Pittsburgh, PA, U.S. A, (2003).

DOI: 10.2172/807633

[13] ABAQUS6. 10 Documentation, http: /www. simulia. com.

[14] Schafer.B. W, Li. Z, Moen C.D. Computational modeling of cold-formed steel. Thin-Walled Structures 2010; 48(10-11): 752-762.

DOI: 10.1016/j.tws.2010.04.008

[15] ENV1993-1-3-2006, Design of steel Structures, Part 1. 3.

[16] Outinen, J. Mechanical properties of structural steels at elevated temperatures. Licentiate thesis, Helsinki University of Technology, (1999).

[17] Tide, Raymond H.R. Integrity of structural steel after exposure to fire. Engineering Journal 1998; 35: 26–38.
