Experimental Study on the Aerator's Air Hole Area, Cavity Length and Backwater in the Cavity

Abstract:

It cannot be ignored that the concrete surface of the discharge works may be seriously damaged caused by high speed flows. However, aerator installed at the bottom of spillway or tunnel is usually used to solve this problem in engineering. The function of the aeration facilities are influenced significantly by the cavity length and the backwater in the cavity, for the air holes will be blocked if there is a serious backwater in the cavity and so the aeration facilities will be ineffective. This thesis aims to study and analysis the relations among the air hole's area, the cavity length and the backwater depth in different conditions by the model experiments. The experiment results indicate that, the area of the air hole is a key factor to influence the jet cavity after the aerator. Aerator's body size and the chute slope affect cavity size and backwater in it greatly. For the chute with small bottom slope, more attention should be paid to the backwater in aerator's cavity.

• Periodical: Applied Mechanics and Materials (Volumes 353-356)
• Pages: 2555-2558
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.353-356.2555
• Online since: August 2013
• Authors: Yan Rong, Yi Min Xu*, Liang Qiao, Guan Bo Ma, Chun Ying Shen
• Keywords: Backwater Depth, Cavity Length, Hydraulics, Small Bottom Slope

References

[1] Wang Haiyun, Dai Guangqing, Yang Qing, Liu Chao. Experimental study on V-type aerator for spillway tunnel with inlet raised [J], Journal of Shuili Xuebao, 2005(11), pp.1371-1374.

[2] Liu Chao, Zhang Guangke, Zhang Guangbi, Wang Haiyun, Li Naiwen. Analysis on length of air cavity of lateral aerators [J], Journal of Shuili Fadian Xuebao, 2007 26(5), pp.112-115.

[3] Qi Lijian, Liao Huasheng, Li Guiji, Zhang Jianmin. Numerical simulation on backwater downstream of aerators in spillway with low Floude number flow[J], Journal of Shuili Xuebao, 2007(7), pp.819-824.

[4] Wang Haiyun, Dai Guangqing, Yang Yongquan, Liu Chao, Yang Qing. Characteristic Study on Preventing Cavitation Damage of Hydraulic Structures Side-walls with High Head[J], Journal of Sichuan University (Engineering Science Edition), 2006(1), pp.38-43.

[5] DL/T5166-2002. Design Specification for River-bank Spillway. Issued by State Economic Trade Commission, China.

[6] Shen Chunying, Xu Yimin, Zhang Tao, Chu Weiwwei. Experiment of ramp-type aerator shape on the impact of aeration under low Froude number[J], Journal of Advances in Science and Technology of Water Resources, 2012, 32(2), pp.15-17.

[7] Zhang Tao, Bai Wenhe, XU Yimin, Shen Chunying, Chu Wei-wei, LIU Xiaolei. Experimental Study of the Effect of Air Vent on the Length of Cavity of Aerators[J], Journal of South-to- North Water Diversion and Water Science & Technology, 2010 8(5), pp.58-60.
