Design of Multi-Mode Microwave Control Combination for InSAR System

Abstract:

This paper provides a multi-mode Microwave Control Combination (MCC) for InSAR system, where the center frequency is F0 with 800 MHz bandwidth, and the size is smaller than 355mm×480mm×155mm. A special InSAR system is introduced with finite baseline between antennas, gets the equal baseline longer by the way of MCC fast switch and makes the channel phrase satisfy the special InSAR system demand. In the MCC design, isolation between antenna channels, high-power and fast channel switch of the system are considered firstly, which are very important in finite airborne space for this InSAR system. The combination system can be changed to three working modes with different configuration but same external interface. This MCC can support average power 400w and peak power 4000w, achieve isolation between radiation channels more than 48dB and channel switch time less than 10μs.

• Periodical: Applied Mechanics and Materials (Volume 367)
• Pages: 401-404
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.367.401
• Online since: August 2013
• Authors: Yuan Yuan, Xue Quan Yan, Zheng Lin Cao
• Keywords: Fast Switch, High-Power, Isolation, Microwave Control Combination, Multi-Mode

References

[1] P. Gamba and B. Houshmand，Comparison of C- and X-Band InSAR Data for 3D Characterization of an Urban Area, ，IEEE AESS Systems Magazine, Page9-15, June (2002).

DOI: 10.1109/maes.2002.1010115

[2] Lei Ying, David C. Munson, Jr., RalfKoetter, Brendan J. Frey, Multibaseline InSAR Terrain Elevation Estimation: a Dynamic Programming Approach, IEEE, (2003).

DOI: 10.1109/icip.2003.1247205
