Influence of the Thickness Value on the Mechanical and Formability Properties of the CuZn37 Thin Sheet Metal

Abstract:

The increase of the degree of miniaturization of the mechanical systems leads to the increase of the production requirements for micro or mili parts made using the micro and milli deep drawing processes. In the case of micro or mili drawn parts, the foil thickness has an important influence on the intensity of the specific phenomena that occur during micro and milli cold forming and has also an important effect on the drawn part integrity or accuracy. The present study was focused on the investigation of the material behaviour, including mechanical properties and forming limit curve of CuZn37 when different thicknesses of foils are used. For this purpose, experimental determinations were made by using the following two values of the foils thickness: 0.1 and 0.2 mm. For each foil thickness, the mechanical properties and the forming limit curves (FLC) were determined and compared. The obtained results concerning the influence of the foil thickness on the material mechanical and formability properties shown that the level of the stress strain curve determined for the foil thickness having 0.1 mm is greater than in the case of foil thickness having 0.2 mm but the maximum strain and the anisotropy coefficients are lower. The level of the forming limit curves (FLC) in the case of foil thickness having 0.2 mm is greater than in the case when the foil thickness is equal to 0.1 mm.

• Periodical: Applied Mechanics and Materials (Volume 371)
• Pages: 163-167
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.371.163
• Online since: August 2013
• Authors: Gheorghe Brabie, Neculai Nanu, Augustin Jitaru
• Keywords: FLC, Formability Properties, Image Correlation, Mechanical Property, Thin Sheet Metal

References

[1] C. Barbier, S. Thibaud, F. Richard, P. Picart, Size effects on material behaviour in microforming, Int. J. Mater. Form. 2 (2009) 625–628.

DOI: 10.1007/s12289-009-0563-0

[2] F. Vollertsen, Z. Hu, H. Schulze Niehoff, C. Theiler, State of the art in micro forming and investigations into micro deep drawing, Journal of Materials Processing Technology. 151(1–3) (2004) 70–79.

DOI: 10.1016/j.jmatprotec.2004.04.266

[3] H. Justinger, G. Hirt, Estimation of grain size and grain orientation influence in microforming processes by Taylor factor considerations, Journal of Materials Processing Technology. 209 (2009) 2111–2121.

DOI: 10.1016/j.jmatprotec.2008.05.008

[4] W.L. Chan, M.W. Fu, J. Lu, J. G. Liu, Modelling of grain size effect on micro deformation behaviour in micro-forming of pure copper, Mat. Sci. Eng.A. 527 (2010) 6638-6648.

DOI: 10.1016/j.msea.2010.07.009

[5] U Engel, R Eckstein, microforming- from basic research to its realization, J. Mat. Proc. Techn. 125-126 (2002) 35-44.

DOI: 10.1016/s0924-0136(02)00415-6

[6] Z. Hu, F. Vollertsen, Modelling of friction with respect to size effects, Int J Mater Form. 1 (2008) 1231 –1234.

DOI: 10.1007/s12289-008-0164-3

[7] F. Gong, B. Guo, C. J. Wang, D. B. Shan, Effects of lubrication conditions on micro deep drawing, Microsyst. Technol. 16 (2010) 1741–1747.

DOI: 10.1007/s00542-010-1108-7

[8] K. F. Zhang, L. Kun, Classification of size effects and similarity evaluating method in micro forming, J. Mat. Proc. Techn. 209 (2009) 4949–4953.

DOI: 10.1016/j.jmatprotec.2008.11.018

[9] Zhenyu Hu, Realisation and application of size dependent FEM-simulation for deep drawing of rectangular work pieces, CIRP Journal of Manufacturing Science and Technology. 4 (2011) 90–95.

DOI: 10.1016/j.cirpj.2011.05.006

[10] N. A. Sène, P. Balland, R. Arrieux, About necking detection to determine forming limit diagrams for mini stamping, 17th Int. Conf. Design and Technol. Drawpieces Die Stampings, Poznan – Poland, 2008, pp.241-254.
