The Shift Speed Control of CVT on Different Conditions

Abstract:

It will cause the drop of the acceleration performance and driving comfort if the continuously variable transmission shift too quickly. So Aiming at the shifting problem of continuously variable transmission system, This thesis put forward the method to control shift speed of the continuously variable transmission based on driving intention. By the dynamics analysis of continuously variable transmission system, it does a research on the influence on the motor automobiles acceleration performance and driving comfort, when the ratio changes too fast. According to working practice, analyzing shift way of continuously variable transmission system. Through the above analysis and findings, the method to control shift speed based on driving intention will be designed to make acceleration and driving comfort unified. And by limiting the maximum CVT ratio change rate, the automobile acceleration performance can be further improved.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 104-107
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.104
• Online since: August 2013
• Authors: Jing Jing Xia
• Keywords: Automobile Engineering, CVT, Driving Intention, Shift Speed

References

[1] He Ren，Ma Chengguang，Zhang Yong，et al. Method to determine target speed ratio of CVT based on driving intention[J]. Transactions of the Chinese Society for Agricultural Machinery. 2009，40(5)：16-20.

[2] Li Yongjun, Chen Shuxing, Cui Yong. The coordinated control of automated mechanical transmission during starting[J]. Automotive Engineering. 2003. 25(2)：178－181.

[3] Guo Yanying, Liu Mingshu, Zhou Yunshan，et al. Engine Modeling and Designing of PID Ratio Controller for automobiles Equipped with CVT[J]. Automobile Technology. 2007，7：14-17.

[4] Chen Shujin，Li Huade，Ran Zhengyun，et al. A Simulation Research on the Longitudinal Acceleration Control of Electric automobiles[J]. Automobile Engineering. 2007，29(4)：304-307.

[5] Xia Jing-jing, He Ren, Zhang Yong, et al. Control Strategy of CVT Clutch Starting Based on Stage Control [J]. Journal of Highway and Transportation Research and Development, 2008, 25(12): 180-183.

[6] Ma Shize，Lei Yucheng. Research of Ratio Control of Metal Pushing V-belt CVT[J]. Journal of Tongji University. 2003，31(2)：209-211.
