Implementation of High Power Power-Over-Ethernet System Based on LTPoE++

Abstract:

A new Power over Ethernet (PoE) proprietary specification known as LTPoE++ and its solution for high power PoE system is introduced. A 90W single port high power PoE system based on the LTPoE++ solution using power sourcing equipment (PSE) controller LTC4274A-4 and powered device (PD) controller LT4275A produced by Linear Technology is illustrated, including overall structure, features, hardware frames, functions and their implementation. Finally working process of the system is analyzed.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 1638-1643
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.1638
• Online since: August 2013
• Authors: Jian Yu Huang, Qi Sheng Zhang, Sheng Quan Zhang
• Keywords: LTPoE++, Power over Ethernet (PoE), Power Sourcing Equipment (PSE), Powered Device (PD)
