A Gabor Filter Based Image Acquisition Method for Raised Characters

Abstract:

This paper presents a novel image acquisition technology for raised characters. First, laser stripes modulated with height information of raised character are captured using the 3D vision technique; then, laser stripes are combined into a grating image, in which are complete character images with grating background; Finally, a rational design Gabor kernel is applied to filter the grating image. Through this way, the background was removed and the grayscale images of the raised characters are reserved. Experiments show that the proposed method can get the well-separated character images. Also, it is more simple and efficient than the existing methods.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 459-463
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.459
• Online since: August 2013
• Authors: Xue Yong Li, Chang Hou Lu
• Keywords: Gabor Filter, Image Acquisition, Raised Character

References

[1] X.Y. Li, C.H. Lu, R. J. Xiao, et al: Sensor Review Vol. 33(2) (2013), p.134.

[2] X.Y. LI, C.H. Lu, J. C. Zhang, et al: Opt. Laser Eng. Vol. 51(2) (2013), p.148.

[3] C. Chanchal, In: SPIE-The International Society for Optical Engineering, Vol. 2622 (1995), p.564.

[4] C. Quan, X.Y. He, C.F. Wang, et al: Opt. Commun. Vol. 189 (2001), p.189.

[5] M.J. Tsai, C.C. Hung: Measurement Vol. 38 (2005)38, p.236.

[6] M. Lades, J. C. Vorbruggen, J. Buhmann, et al: IEEE Trans. Comput., vol. 42(3) (1993), p.300.

[7] L. Wang, Y.P. Li , C. B Wang, et al: Image. Vison Comput., Vol, 26 (2008), p.820.

[8] X. W Wang, X.Q. DinG, C.S. Liu: Pattern Recogn., Vol. 38 (2005), p.369.
