Fault Diagnosis of Broken Bars in Induction Motors Using EMD

Abstract:

This paper presents a diagnosis method based on EMD, in order to improve the precision of fault diagnosis in induction motors. After the Park vector analogue signal of stator current is decomposed by EMD, 2sf fault characteristic value is abstracted accurately. Simulation results show that this proposed method is of high sensitivity, efficiently solves the problem that frequencies of fault and fundamental wave are close and difficult to be decomposed.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 861-864
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.861
• Online since: August 2013
• Authors: Xiao Quan Li, Jing Chen Wang, Run Ling Li
• Keywords: Broken Bars, Empirical Mode Decomposition (EMD), Fault Diagnosis, Induction Motor (IM), Park Vector

References

[1] Huang N E, Shen Z, Long S R, et al. The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-station time series analysis [J]. Proceedings of the Royal Society of London Series A, 1998, 454 (3): 903-995.

DOI: 10.1098/rspa.1998.0193

[2] Xu J M, Wang F Z, Yin X, et al. A traveling wave fault location method for high voltage power transmission lines based on HHT transform [J]. Power system protection and control, 2012, 40(2): 88-92. (in Chinese).

[3] Sun H. EMD theory and application [D]. Hangzhou: Zhejiang University, (2005).

[4] Li R Y, He D. Rotational Machine Health Monitoring and Fault Detection Using EMD-Based Acoustic Emission Feature Quantification [J]. IEEE Transactions on Instrumentation and Measurement, 2012, 61 (4): 990-1001.

DOI: 10.1109/tim.2011.2179819

[5] Liu Z X, Yin X G, Zhang Z. On-line Monitoring and Diagnosis Way Based on Spectrum Analysis of Hilbert Modulus in Induction Motors [J]. Proceedings of the CSEE, 2003, 23 (7): 158-161. (in Chinese).

[6] Dong Tao, CHeng P Y; Fan Bo. Detection for Broken Bar Based on Frequency Spectrum Analysis of Hilbert Modulus[J], Electric Machines & Control Application, 2010, 37(2): 53-56. (in Chinese).

[7] Chang X R, Cocquempot V, Zhao S Q. The New Three Phase Asynchronous Machine Model and Simulation Experiment [J]. Proceedings of the CSEE, 2003, 23 (8): 140-145. (in Chinese).

[8] Guo Y P, Yan W J, Bao Z J, et al . Fault diagnosis of bearing in wind turbine based on EMD and divergence index [J]. Power system protection and control, 2012, 40(17): 83-87. (in Chinese).
