Finite Element Analysis for Assembly Fixtures Based on ANSYS

Abstract:

Structure analysis is a vital link while designing aircraft assembly fixtures. ANSYS software is applied to analyze the structure of an aircraft assembly fixture based on a general method proposed in this paper. Firstly, a frame-type riveting assembly fixture is modeled, the static load and the boundary condition is preset according to the requirement of finite element analysis. Secondly, the static stiffness and strength is calculated considered both the condition with and without working load. Finally, the analysis and optimization process is conducted. The effectiveness and feasibility of this method has been proved combined with the simulation result and the reality test. The method can be applied to other aircraft assembly fixture when taking finite element analysis, thus it has the application and popularization value.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 173-176
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.173
• Online since: August 2013
• Authors: Wei Cao, Guo Lei Zheng, Jing Lin Xu, Yi Qiu
• Keywords: Assembly Fixture, Finite Element, Structure Analysis

References

[1] L. Di Sarno, A.S. Elnasha. Bracing Systems for Seismic Retrofitting of Steel Frames[J]. Journal of Constructional Steel Research, 2009, 65(2): 452-465.

DOI: 10.1016/j.jcsr.2008.02.013

[2] Deng Yadong, She Yini. Finite Element Modeling and Analyzing for a Bus Body Based on ANSYS[J]. Journal of Wuhan University of Science and Engineering, 2005, 18(9): 40-42.

[3] Chen Zhihua. Main Steel Structure Analysis and Important Nodes Study of Tianjin Library[D]. Tianjin: Tianjin University, (2011).

[4] Zhu Xiaowu. The Strength and Fatigue Analysis of the Automobile Subframe[D]. Zhenjiang: Jiangsu University, (2011).

[5] Xiao Fang, Wu Tao, Zhao Wenjie, et al. The Safety Design of Body in Field Operationed Vehicles[J]. Journal of Xihua University•Natural Science, 2013, 32(2): 54-59.

[6] Zhu Hehua, Miaoyuan Bing, Liang Wei, et al. Problems in Calculating Composite Structure with FEM and Their Countermeasures[J]. Rock and Soil Mechanics, 2005, 26(9): 1437-1442.

[7] Liu Chengwu, Liang Huiquan, Hong Liang. Structure Analysis of Bus Body Frame Topological Optimization[J]. Mechanical & Electrical Technology, 2013(1): 2-4.

[8] Cui Xiaoqiang, Gao Zhenfeng, Li Zixu, et al. Simplified Analysis Method of Large Complex Temporary Supports[J]. Spatial Structures, 2005, 11(1): 45-49.

[9] Zhao Zuozhou, Liu Zhiqing, Kang Hongzhen, et al. A Survey of Bracing Forms in Braced Frame Structure[J]. Industrial Construction, 2011, 4(8): 79-84.

[10] Chen Zhihua, Zhou Ting, Wang Xiadun. Application of Special Shaped Column Composed of Concrete-filled Steel Tubes[J]. Advanced Materials Research, 2011, 163(167): 196-199.

DOI: 10.4028/www.scientific.net/amr.163-167.196
