The Control System Design of AC Servo PMSM Based on an EMCU

Abstract:

The mathematical vector model of a permanent magnet synchronous motor (PMSM) has first been discussed in this paper, and a servo control system based on Space Vector Pulse Width Modulation (SVPWM) has been designed, in which a enhanced Microprogrammed Control Unit (EMCU) is combined with drive chips and the relevant control software to achieve the precise control of PMSM. In order to control the position, speed and current of the PMSM, six SVPWM signals are generated with the motor vector control method, and the vector control strategy with three closed loops is projected. According to the control principle, the circuits of the hardware modules are designed and built, and the program of the control process is compiled and downloaded the EMCU, and then the human-computer interaction interface of the system is implemented by LabVIEW. The results of the test show that the control system designed can control the rotating speed and the high-speed pendulum operation of PMSM precisely.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 309-312
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.309
• Online since: August 2013
• Authors: Xue Wen Wang, Zhou Hu Deng, Xiao Yun, Long Zhang, Yuan Zhang
• Keywords: Control, PID, PMSM, Servo, SVPWM
