Study of Droop Characteristic in Advanced Co-Phase Traction Power Supply System

Abstract:

The disadvantages of two existing traction power supply modes are analyzed and advanced co-phase traction power supply system based on three-phase to single-phase converter is studied in the paper. Then, the chain model of network and the constant power model of locomotive are established. According to the above results, further analysis of the circulating-impedance and the feasibility study of droop control in this system are presented. The circulating-current analysis results of the advanced co-phase traction power supply system and the droop control of the system are given in the end of the paper.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 3118-3123
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.3118
• Online since: August 2013
• Authors: Yuan Wang, Xiao Qiong He, Ze Liang Shu, Zheng Xiang Xu, Ying Ying Zhou
• Keywords: Advanced Co-Phase System, Droop Characteristic, Impedance Analysis

References

[1] Q.Z. Li, Comprehensive analyses on fixed parallel compensation used in 3-phase traction substations, Journal of The China Railway Society, vol. 1, pp.9-17, September, (1987).

[2] Z.L. Shu, S.F. Xie, and K. Lu, Digital Detection, Control, and Distribution System for Co-phase Traction Power Supply Application , IEEE Transactions on Industrial Electronics，vol. 9(1), pp.1-9, 2012.

DOI: 10.1109/tie.2012.2190959

[3] Z.L. Shu, S.F. Xie, and Q.Z. Li, Single-Phase Back-To-Back Converter for active Power Balancing, Reactive Power Compensation, and Harmonic Filtering in Traction Power System, IEEE Traction on Power Electronics，vol. 26(2), pp.334-343, 2011.

DOI: 10.1109/tpel.2010.2060360

[4] X.Q. He, Y. Wang, Z.L. Shu, and Q.Z. Li, Multiple AC-DC-AC Substations Traction Power Supply System Simulation, 2012 IET International Conference on Information Science and Control Engineering, Shenzhen, China, (2012).

[5] A.L. Chen X.N. He，and L. Hu, Research on combined multilevel converter topologies, Proceedings of the CSEE，vol. 26(14), pp.41-46, 2006.

[6] Z.Y. He, H.T. Hu, and L. Fang, Research on the Harmonic in High-speed Railway Traction Power Supply System and Its Transmission Characteristic, , Chin. Soc. for Elec. Eng, vol 31(16), Jun. 5, (2011).

[7] H.T. Hu, Z.Y. He, M. Zhang, Series Resonance Analysis in High-speed Railway All-parelle AT Traction Power Supply System, , Chin. Soc. for Alec. Eng, vol 32(13), May. 5, (2012).

[8] R. H. Lasseter, Micro-grids, Power Engineering Society Winter Meeting, New York, USA, 2002.

[9] Rubens M. Santos Filho, Paulo F. Seixas, Porfirio C. Cortizo, Leonardo A.B. Torres, and Andre F. Souza, Comparison of Three Singe-Phase PLL Algorithms for UPS Applications, IEEE Traction on Industrial Electronics ，vol. 55(8), pp.2923-2932, 2008.

DOI: 10.1109/tie.2008.924205

[10] Q.Z. Li, and J.M. He, Analysis of Traction Power Supply System, , Chengdu: Southwest Jiaotong University Press, 2007, pp.69-101.

[11] Q.Z. Li, and J.M. He, Electrified Railway Feeding System Without Phase Exchange And Symmetrical Compensation Technology, Automation of Electric Power System, vol. 20(4), pp.9-11, April, (1996).
