Stochastic Assessment of Voltage Sag Considering the Time Characteristic of Protection System

Abstract:

When fault occurs in power system, the duration of voltage sag is determined by the fault clearing time of the protection system. In order to describe the duration of voltage sag more accurately, the time characteristic of protection system is considered for stochastic assessment of voltage sag. Based on the traditional assessment model, the mapping relationship between the time characteristic of protection system and voltage sag frequency is established using fault positions method. The proposed method is applied to the IEEE-30 bus test system, simulation results show that the time characteristic of protection system has an obvious influence on the duration of voltage sag, and very serious errors will be produced if the time characteristic of protection system is ignored. The proposed method is simple, adaptive and practical, and it is of academic value and practical foreground.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 3160-3165
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.3160
• Online since: August 2013
• Authors: Li Pin Chen, Xian Yong Xiao, Yu Tao Qiu, Qian Xiong
• Keywords: Duration, Protection System, Stochastic Assessment, Time Characteristic, Voltage Sag

References

[1] J. Y. Chan，J. V. Milanovic， A. Delahunty．Risk-based assessment of financial losses due to voltage sag, IEEE Trans. on Power Delivery， vol. 26, p.492–500, (2011).

DOI: 10.1109/tpwrd.2009.2037426

[2] M. H. J. Bollen, K. Stockman, R. Neumann．Voltage dip immunity of equipment and installations - messages to stakeholders, 15th International Conference on Harmonics and Quality of Power (ICHQP 2012), IEEE Press, June 2012, pp.915-919.

DOI: 10.1109/ichqp.2012.6381173

[3] M. T. Aung， J. V. Milanovic．Stochastic prediction of voltage sags by considering the probability of the failure of the protection system, IEEE Trans. on Power Delivery，vol. 21, p.322–329, (2006).

DOI: 10.1109/tpwrd.2005.852385

[4] C. H. Park， G. Jang， R. J. Toms．The influence of generator scheduling and time-varying fault rates on voltage sag prediction, IEEE Trans. on Power Delivery， vol. 23, p.1243–1250, (2008).

DOI: 10.1109/tpwrd.2008.915836

[5] H. Q. Li， X. Y. Xiao， Y. Wang，W. Chen．Probability evaluation method of equipment failure due to voltage sags considering multi-uncertain properties, Electrical Power and Energy Systems， vol. 33, p.608–614, (2011).

DOI: 10.1016/j.ijepes.2010.11.015

[6] C. P. Gupta， J. V. Milanovic．Probabilistic assessment of equipment trips due to voltage sags, IEEE Trans. on Power Delivery， vol. 21, p.711–718, (2006).

DOI: 10.1109/tpwrd.2005.855447

[7] C. H. Park， G. Jang．Stochastic estimation of voltage sags in large meshed network, IEEE Trans. on Power Delivery， vol. 22, p.1655–1664, (2007).

DOI: 10.1109/tpwrd.2006.886795
