Parachute Swing Angle Measurement in Wind Tunnel Test Based on Stereo Vision System

Abstract:

Parachute system is a significant composing part of aircraft, and the swing angle is one of system security targets. To the complicated measurement problem of parachute angle in wind tunnel test, this paper describes a test method based on stereo vision system, the system is mainly composed of two CCD cameras, image acquisition card and computer. It can get 3D coordinates by stereo vision calibration and digital image processing technology, and calculate the parachute swing angle by geometry relationship. The result shows that the method succeeds, and gets the vertical and horizontal angles which are projected onto two orthogonal planes. The method has the advantage of simple system composing and good compatibility, displays much better application value.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 837-840
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.837
• Online since: August 2013
• Authors: Jin Song, Jun Ma, Min Jiang
• Keywords: Parachute Swing Angle, Stereo Vision Measurement System, Wind Tunnel

References

[1] Tsai R Y. A Versatile Camera Calibration Technique for High2accuracy 3D Machine Vision Metrology Using Off2the2shelf TV Camera and Lenses[J]. IEEE Journal of Robotics and Automation, (1987).

DOI: 10.1109/jra.1987.1087109

[2] Zheng Shengzi. Novel Design of Low Cost Mobile Robot Lazer Scanner [J]. Computer Measurement & Control, 2011. 19(5): 1094-1097.

[3] Ma Songde, Zhang Zhengyou. Computer Vision-Computer Theory and Algorithm[M]. Beijing: Science Press, (2003).

[4] Qin Xiangpei. MATLAB Digital Image Processing and Programming Interface[M]. Beijing: Publishing House of Electronics Industry, (2009).

[5] He Dongjian. Digital Image Processing [M]. Xii`an: Xidian University Press, (2007).
