An Optimal Design of PI Control in the Application of Active Power Filter

Abstract:

This paper mainly introduces an optimal design of PI control based on compensation to eliminating the interference and improving the performance of the system. With the mathematic model of shunt APF in d-p rotating coordinate, simulation indicates that there is a period disturbing signal in the current closed loop of shunt APF based on the conventional PI control, which obviously impacts on the current tracking performance of the system. So a new PI control based on compensation is put forward. Through the simulation in the platform of Matlab/Simulink, it turns out that this method can improve the current tracking performance of APF and stable performance of the system.

• Periodical: Applied Mechanics and Materials (Volumes 385-386)
• Pages: 1220-1223
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.385-386.1220
• Online since: August 2013
• Authors: Yun Liang Wang, Xiao Feng Yu
• Keywords: Active Power Filter (APF), Compensation, Current Track, PI Control

References

[1] Qu Xueji, Qu Jingkai, and Yu Mingyang, et. Power electronic filtering technology and its application [M]. Beijing: Electronic Indus- Industry Press (2008).

[2] Wang Zhao and Zeng Guohong. Design and research on control system of Active Power Filter based on DSP [M]. Power Capacitor (2007).

[3] Fang Xin, Current digital control technology of shunt Active Power Filter. Huazhong university of science and technology, (2006).

[4] Paolo, Mattavelli Member, and Fernando. Repetitive-Based Control for Selective Harmonic Compensation in Active Power Filter (2004).

[5] Trzynadlowski A. M, Kirlin R L and Legowaki S.F. Space Vector PWM Technique with Minimum Switching Losses and Variable Pulse Rate. IEEE Transactions on Industrial Electronics, (1997) 4 4(2): 173-181.

DOI: 10.1109/41.564155
