Stiffness Optimization for Springs in a Gun Cartridge Retaining Mechanism

Abstract:

To prolong the life of cartridge retaining pawl and link stopper in a gun cartridge retaining Mechanism, three compression springs stiffness are reduced via design study and optimization design based on dynamic analysis. Presenting the load of shell on a typical stage while entering-bore, differential equations of motion in this mechanism are established. With translational velocity of shell as the design variable, a design research and simulation analysis are made. And the relationship between shell velocity and proper shell-feed is acquired. An evaluation function is built using springs stiffness with preference-selection. With this evaluation function as the optimum objective, spring stiffness as design variables, and proper shell-feed as constraint condition, the minimum of three spring stiffness is obtained after calculation. The results indicate that compared with the original design parameters optimization results, are significantly improved with the stiffness decreased separately by 20.27%, 11.99% and 6.86%.

• Periodical: Applied Mechanics and Materials (Volumes 385-386)
• Pages: 163-167
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.385-386.163
• Online since: August 2013
• Authors: Long Miao Chen, Lin Fang Qian, Rui Xue Zhao
• Keywords: Cartridge Retaining Mechanism, Design Study, Mechanical Engineering, Optimization, Spring Stiffness

References

[1] I.A. McGregor. Telescoped Ammunition: A Future Lightweight Compact Ammunition?[J]. Canadian Army Journal. 2009, 12(2): 75-81.

[2] Clifford E. LaFever, Mission Viejo, William J. Washburn, et al. Ammunition Round [P]. US: 4197801, (1980).

[3] Li Zhili, Cao Ning. Progresses and trends on small caliber automatic and ammunition [J]. Land-Based Air Defence Weapons．2004(1): 52~54. (In Chinese).

[4] Xu Cheng, Wang Yaping. Dynamics of Gun and Automatic Weapon [M]. Beijing: Beijing Institute of Technology Press, 2006. (In Chinese).

[5] Mao Baoquan, Shao Yi. Optimization Design of Gun and Automatic Weapon[M]. Beijing: National Defense Industry Press, 2007. (In Chinese).

[6] Liu Weixin. Mechanical Optimal Design[M]. Beijing: Tsinghua University Press, 1993. (In Chinese).

[7] Sung-Pil Jung, Tae-Won Park, etc. Design optimization of spring of a locking nut using design of experiments [J]. International Journal of Precision Engineering and Manufacturing. 2009 (10): 77~83.

DOI: 10.1007/s12541-009-0074-4
