Force and Simulation Analysis of Thrust Rod on Heavy Commercial Vehicle Balanced Suspension

Abstract:

The thrust rod is the key load-bearing part of the balanced suspension on heavy commercial vehicle. In order to optimize the structure and study the durability of it, we carried out the force and simulation analysis. In this paper, the model of thrust rod and guide mechanism was simplified. Under all driving conditions, force analysis was done for fully-loaded vehicle and force calculation formulae of thrust rods in different directions were derived. Multi-body dynamics model of the vehicle was established with ADAMS and we compared the differences of the two algorithms. Then the results of the two algorithms were compared with the load spectrum test results. We find the calculated results are in good agreement with engineering requirements.

• Periodical: Applied Mechanics and Materials (Volume 387)
• Pages: 94-99
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.387.94
• Online since: August 2013
• Authors: Zan Li, Wen Ku Shi, Qian Wang, Jun Ke, Teng Teng, Yu Fei Zhou, Tian Yun Liu, Zhi Yong Wu, Yong Wei Dong
• Keywords: Balance Suspension, Force Analysis, Simulation Analysis, Thrust Rod

References

[1] C.F. Zhou, G.Q. Zhao, H.H. Zhang, X.K. Chen: Research on Mechanical Performance Analysis and Structural Modification of Longitudinal Thrust Rod[J]. Advanced Materials Research, Vol. 584 (2012), pp.357-362.

DOI: 10.4028/www.scientific.net/amr.548.357

[2] G.S. Feng, S.M. Jia, N. Li, H. Lin: Push Rod Failure Analysis of a mining heavy dump truck[J]. Engineering Failure Analysis, Vol. 25(2012), pp.193-199.

DOI: 10.1016/j.engfailanal.2012.05.006

[3] G. Ju, H.B. Li, Y.Z. Xiu: Design Match of Thrust Rod in Heavy Engineering Truck[J]. Technic Forum (2012).

[4] S.A. Hu, J.P. Song: Design and Check of Thrust Bar in Heavy Truck[J] . Technic Forum (2012).
