Study on Voltage Stability Weak Buses of Power System with Multiple Power Sources Integrated

Abstract:

To obtain the distribution of voltage stability weak buses (VSWB) for power system with multiple power sources integrated, so as to provide a basis for voltage stability control, an analysis method under full time frame is proposed in this paper. Based on the modeling of multiple power sources, combined with the load prediction, the active power output prediction of wind and photovoltaic power and the generation scheduling of conventional power, considering different patterns of load increase and power output increase and allocation of multiple power sources, within a certain period of time and for the specifically selected time sections, the continuation power flow method is respectively used to get the voltage stability critical point (SNB point), where modal analysis is applied, so that the VSWB are obtained of the certain time section. The same calculation is carried out for all the time sections selected, and then the distribution and occurrence frequency of VSWB are summed up, thereby acquiring the concrete condition of VSWB within such certain time period. Its considered that the condition of VSWB can be affected by the different integration buses and penetration rates of multiple power sources. The proposed method is verified on the IEEE 118-bus system, as well as the fact with practical significance that the condition of VSWB varies with the difference of integration buses and the penetration rates of multiple power sources.

• Periodical: Applied Mechanics and Materials (Volume 391)
• Pages: 281-286
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.391.281
• Online since: September 2013
• Authors: Jia Long Li, Wei Wei
• Keywords: Integration Bus, Multiple Power Sources, Penetration Rate, Voltage Stability, Weak Bus

References

[1] Zhou Shuangxi, Zhu lingzhi, Guo Xijiu, et a1．Power System Voltage Stability and Control. (China Electric Power Press, China 2004).

[2] Gao Peng, Shi Libao, Yao Liangzhong, et a1．A Multi-Criterion Integrated Voltage Stability Index for Weak Buses Identification. Power System Technology, 2009, 33(19): 26-31.

[3] Fu Wanxue, Zhang Weidong, Xing Yingchun. Study on Weak Buses of Voltage Stability Based on Static Voltage Stability Analysis. Electric Power Science and Engineering, 2011, 27(3): 41-46.

[4] Chen Jinfu, Chen Haiyan, Duan Xianzhong, Multi-Period Dynamic Optimal Power Flow in Wind Power Integrated System. Proceedings of the CSEE, 2006, 26(3): 31-35.

DOI: 10.1109/tdc.2005.1546979

[5] Wang Yibo, Wu Chunsheng, Liao Hua, et a1. Steady-state Power Flow Analyses of Large-scale Grid-connected Photovoltaic Generation System. Journal of Tsinghua University(Science and Technology), 2009, 49(8): 1093-1097.

DOI: 10.1007/978-3-540-75997-3_333

[6] Li Bin，Liu Tianqi，Li Xingyuan．Impact of Distributed Generation on Power System Voltage Stability[J]．Power System Technology，2009，33(3)：84-88.

[7] Liao Chengbin, Wen Buying, Jiang Yuewen. Study on Weak Buses of System Voltage Stability with Wind Power Integrated. Power System and Clean Energy, 2011, 27(10): 82-86.

[8] Gao B, Morison G.K., Kundur P. Voltage Stability Evaluation Using Modal Analysis. IEEE Transactions on Power Systems, 1992, 7(4): 1529-1536.

DOI: 10.1109/59.207377

[9] Jiang Wei. Calculation of Critical Point of Power System Static Voltage Stability Based on Direct Method. Tianjin: Tianjin University, (2005).

[10] Lin Li, Xie Yongjun, Zhu Chenchen, et a1. Priority List-Based Output-Restricted Active Power Control Strategy for Wind Farms. Power System Technology, 2013, 37(0): 1-7.
