The Research on Automatic Generation of Process Diagram in CAPP System for Shaft Parts

Abstract:

Automatic generation of process diagram is developed in CAPP for shaft parts. The processing code to express the processing is used as a link to get the information of process diagram from the parts and processing information, so the topological relationship is established between the various components of surface on parts. The parts diagram, the rough diagram and process diagram are drawn by graphics sub-module with the shape feature flatten based on graph theory and the diagram related marking is also completed. Practical instances are given to analyze and verify.
