Deformation Characteristic of Thin Stainless Gasket Material

Abstract:

Previous studies on corrugated metal gaskets have established that the contact width, contact stress, and surface roughness are important design parameters for optimizing gasket performance. However, the metal gaskets studied previously required a high axial force for the tightening process; in addition that metal gaskets tend to corrode easily. In this study, we examined the deformation mode of a thin stainless gasket using a finite element method (FEM) analysis. A final evaluation was made using a compression examination. The analysis based on the dimension of flat and convex portion. The load, deformation mode, and contact stress were obtained through a simulation. Based on the deformation of the flat and convex portions, the deformation modes were divided into three types. The deformation mode of the thin stainless gasket material has a higher probability of deformation in mode I when the aspect ratio of the length of the flat portion to the length of the convex portion, L/D, increases.

• Periodical: Applied Mechanics and Materials (Volume 392)
• Pages: 3-8
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.392.3
• Online since: September 2013
• Authors: Haruyama Shigeyuki, Didik Nurhadiyanto, Kazuya Ushijima, Ken Kaminishi, Dai Heng Chen
• Keywords: Contact Width, Deformation, Finite Element Method (FEM), Gasket Material, Mode, Thin Stainless

References

[1] Saeed, H. A, Izumi, S., Sakai, S., Haruyama, S., Nagawa, M., Noda, H., Development of New Metallic Gasket and its Optimum Design for Leakage Performance, Journal of Solid Mechanics and Material Engineering, Vol. 2, No. 1 (2008), 105–114.

DOI: 10.1299/jmmp.2.105

[2] Haruyama, S., Choiron, M.A., Kaminishi, K., A Study of Design Standard and Performance Evaluation on New Metallic Gasket, Proceeding of the 2nd International Symposium on Digital Manufacturing, Wuhan China, (2009), 107–113.

[3] Choiron, M.A., Haruyama, S., Kaminishi, K., Simulation and Experimentation on the Contact Width of New Metal Gasket for Asbestos Substitution, International Journal of Aerospace and Mechanical Engineering, Vol. 5, No. 4 (2011), 283–287.

[4] Nurhadiyanto, D., Choiron, M.A., Haruyama, S., Kaminishi, K., Optimization of New 25A-size Metal Gasket Design Based on Contact Width Considering Forming and Contact Stress Effect, International Journal of Mechanical and Aerospace Engineering, Vol. 6 (2012).

DOI: 10.7763/ijmo.2011.v1.26

[5] Ushijima, K., Haruyama, S., Kaminishi, K., Study on Deformed Mode of Metal Seal Materials Using Elastic Effect, Proceeding of the 8th International Conference on Innovation and Management, (2011).

[6] JIS Z2241, Metallic materials-Tensile testing-Method of test at room Temperature, Japanese Standards Association, (2011).
