Design of Multi-Stage Optimal Arbitrary Time-Delay Filter

Abstract:

Input shaping is an effective method for suppressing residual vibration of flexible system. In this paper, the design processes of Zero Vibration (ZV), Zero Vibration and Derivative (ZVD) shapers are deduced. Based on the idea of the robustness input shaper, the Multi-stage Optimal Arbitrary Time-delay Filter (MOATF) is proposed. The proposed control method is implemented on the second-order linear time-invariant system. Simulation results show that the residual vibration can be reduced effectively and the proposed method have great robustness in system parameter uncertainty.

• Periodical: Applied Mechanics and Materials (Volumes 397-400)
• Pages: 1510-1514
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.397-400.1510
• Online since: September 2013
• Authors: Ke Ping Liu, Jian Peng Zeng, Min Yang, Chang Hong Jiang
• Keywords: Input Shaping, MOATF, Robustness, Vibration Suppression

References

[1] H. Yang, J.Z. Hong, Z.Y. Yu, Survey of experiments for dynamics of flexible multibody system, Advances in Mechanics, vol. 34: 171-174(2004).

[2] M. M. Fateh, Robust control of flexible-joint robots using voltage control strategy, Nonlinear Dynamics, vol. 67, no. 2, pp.1525-1537(2012).

DOI: 10.1007/s11071-011-0086-3

[3] Z.D. Hong, C. Yun, L. Chen, Modelling and trajectory tracking control of a free-floating space robot with flexible manipulators, Robot, vol. 29: 92-96(2007).

[4] Z.S. Song, J.Q. Yi, D.B. Zhao, et al, A computed torque controller for uncertain robotic manipulator system: fuzzy approach, Fuzzy Sets and Systems, vol. 154, no. 2, pp.208-226(2005).

DOI: 10.1016/j.fss.2005.03.007

[5] Y.C. Chang, H.M. Yen, Design of a robust position feedback tracking controller for flexible-joint robots, Control Theory & Applications, IET, vol. 5: 351-363(2011).

DOI: 10.1049/iet-cta.2010.0166

[6] N.C. Singer, W.P. Seering, Preshaping command inputs to reduce system vibration, Journal of Dynamic Systems, Measurement and Control, vol. 112: 76–82(1990).

DOI: 10.1115/1.2894142

[7] J. Mao, K.P. Liu, Y.C. Li, Oscillation suppression for a class of flexible system with input shaping technique, Proceedings of the 1st IEEE International Conference on Machine Learning and Cybernetics, vol. 10: 2108-2111(2003).

DOI: 10.1109/icmlc.2002.1175410

[8] K.P. Liu, Experimental evaluation of preshaped inputs to reduce vibration for flexible manipulator, Proceedings of the 6th IEEE International Conference on Machine Learning and Cybernetics, vol. 8: 2411-2415(2007).

DOI: 10.1109/icmlc.2007.4370549

[9] M.C. Pai. Robust input shaping control for multi-mode flexible structures, International Journal of Control, Automation, and Systems, vol. 9: 23-31(2011).

DOI: 10.1007/s12555-011-0104-8

[10] D.P. Magee, W.J. Book, Optimal filtering to minimize the elastic behavior in serial link manipulators, Proceedings of the American Control Conference, Philadelphia: 2637-2642(1998).

DOI: 10.1109/acc.1998.688327
