Thermal Characteristics of High-Power LED Packages with Dissipation Film

Abstract:

A simple, fast, and reliable characterization method for measuring junction temperature (Tj) on high power GaN-based light emitting diodes (LED) was presented in this study. Thermal characteristics of high power Light-emitting-diode have been analyzed by using a three-dimensional thermal conduction model. Maximum operation temperature has also been calculated. The induced thermal behaviors of the best package processes for LED device with diamond film were investigated by finite element analysis (FEA) and by experimental measurement. The large change of forward operation voltage with temperature in light emitting diodes is advantageously used to measure junction temperature. Using this method, junction temperature (Tj) of LED under various structures and chip mounting methods was measured. It was found that the junction temperature can be reduced considerably by using diamond film substrates to replace sapphire substrate. In this study, the junction temperature can be decreased by about 14.3% under 1.5W power and decreased by about 15.9% under 1W power for 1mm square die. The thermal resistance (RT) can be measured to be 14.8°C/W under 1.5W power and 16.6°C/W under 1.W power.

• Periodical: Applied Mechanics and Materials (Volumes 397-400)
• Pages: 1767-1771
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.397-400.1767
• Online since: September 2013
• Authors: Cheng Yi Hsu, Yu Li Lin*
• Keywords: Diamond Film, Junction Temperature, Light Emitting Diode (LED)

References

[1] Nie-Chuan CHEN, Chih-Min LIN, Yen-Kai YANG, Chi SHEN, Tong-Wen WANG1, and Meng-Chyi WU1, Jpn. J. Appl. Phys., Vol. 47, No. 12, (2008).

[2] R. Huber, Thermal Management of SMT LED., Osram Opto-semiconductors (8/02).

[3] Schang-jing Hon, Cheng Ta Kuo, T.P. Chen, M.H. Hsieh , Proc. of SPIE Vol. 6894, 689411, (2008).

[4] M. Y. Tsai, C. H. Chen, and C. S. Kang, 978-1-4244-2231-9/08, 2008 IEEE.

[5] Cheng-Yi Hsu, Yuli Lin, Junction Temperature of High-Power LED Packages with Diamond film, pp.785-786, 2010 IEEE INEC.

DOI: 10.1109/inec.2010.5424493

[6] T. Cheng, X. Luo, S. Huang, S. Liu Thermal Analysis and Optimization of Multiple LED Packaging Based on a General Analytical Solution, International Journal of Thermal Sciences Vol 49, p.196–201, (2010).

DOI: 10.1016/j.ijthermalsci.2009.07.010

[7] O. S. Ling, Thermal Modeling of High Power LEDs, Solid-State Illumination Division, Avago Technologies, (2010).

[8] S. W. Kang, K. C. Chien and W. C. Lin, Thermal Analysis and Test of The Multiple-Layer Heat Dissipating Module for LED Streetlamps, 10th IHPS, NOV 6-9, Taipei , Taiwan, (2011).

[9] P. Anithambigai, K. Dinash, D. Mutharasu, S. Shanmugan, Choon Kim Lim, Thermal Analysis of Power LED Employing Dual Interface Method and Water flow as a Cooling System, Thermochimica Acta, 523, p.237– 244, (2011).

DOI: 10.1016/j.tca.2011.06.001

[10] Yi-Bing Liu, On Thermal Structure Optimization of a Power LED Lighting, Procedia Engineering 29, p.2765 – 2769, (2012).

DOI: 10.1016/j.proeng.2012.01.387
