Design and Implementation of Constant Palstance Control System of Combine Cylinder Based on STM32

Abstract:

Combine harvesters are widely used in agricultural production. Keeping the palstance of combine threshing cylinder constant when the combine works normally has important implications, through which can improve the efficiency and guarantee the quality. In this paper the Foton Lovol GF40 combine is used as the controlled object, then a constant palstance control system is designed based on STM32, and the control program is also designed based on the fuzzy PID algorithm. The control system can receive the signals of feed quantity and cylinder palstance, then drive the HST system and change the walking speed according to the change of the signals received, thus to control the cylinder palstance. Field trials verify the feasibility of the system, show that the system has a certain stability, which can achieve the desired effect.

• Periodical: Applied Mechanics and Materials (Volume 404)
• Pages: 592-598
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.404.592
• Online since: September 2013
• Authors: Jian Li Yan, De An Zhao, Yun Qin
• Keywords: Combine, Constant Palstance Control, STM32

References

[1] Qin Yun, Zhao Dean, Li Fazhong: Constant palstance control of combine cylinder based on RBF[J], Transactions of the Chinese Society for Agricultural Machinery, 2009, 40(11): 59-63.

[2] Li Guodong, Li Yongzhi, Zhang Jixian: PID control of constant palstance of a combine cylinder[J], Transactions of the Chinese Society for Agricultural Machinery, 2000, 31( 1): 48-50.

[3] Li Guodong, Han Jincang, Sang Zhengzhong: Design of intelligent controller of constant palstance of cylinder of the combine[J], Control Engineering of China, 2007, 14(2): 154-156.

[4] Lu Wentao, Zhang Dongxing, Deng Zhigang: Constant load PID control of threshing cylinder incombine[J], Transactions of the Chinese Society for Agricultural Machinery, 2008, 39( 5): 49~ 55.

[5] Ji Jiangtao, Wang Rongxian, Fu Lijun: Grey prediction fuzzy PID control of the feeding quantity in combine[J], Transactions of the Chinese Society for Agricultural Machinery, 2008, 39(3): 63-66.

[6] Weng Shihong: Design and Simulation on Fuzzy Control System of Cylinder for Combine Harvester[j], Journal of Hunan university of Science and Engineering, 2010, 31(4): 129-132.

[7] Wan Tao, Chu Yimin: Auto-matic control system of walking velocity on combine[J], Journal of Agricultural Mechanization Research, 2008, 14( 9 ): 53-56.
