Research on the Concrete Structure Deformation Properties of Xiangjiaba Ship Lift Tower

Abstract:

The passing dam building of Xiangjiaba water conservancy project adopts gear-rack climbing vertical structure. The structure demands highly on the deformation compatibility of relative displacement between tower and nut column, and rack and guide. If it is constructed poorly, it will directly influence the ship lifts running and construction period. The paper takes this as its key research object. 3D FEM is used to analyze the tower structure, mainly calculating the deformation of the tower under the temperature, weight, wind load and other loads in a normal single case and combination cases. By focusing on the theory analysis of the important parts such as nut column, rack and guide, the structures deformation fitness, this paper offers a fair theoretical reference and technological guidance to the construction of every part of the tower.

• Periodical: Applied Mechanics and Materials (Volumes 405-408)
• Pages: 1212-1216
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.405-408.1212
• Online since: September 2013
• Authors: Song Hui Li, Guo Xin Zhang, Yi Liu
• Keywords: Deformation, Fitness, Load, Ship Lift, Tower

References

[1] Zhang Guo-Xin, Li Songhui. XiangJiaBa Shiplift Tower structural static safety and reliability assessment [R]. China Institute of Water Resources and Hydropower Research, Beijing, (2011).

[2] Niu Xin-qiang, key technology research on the structure of Three Gorges Shiplift [D]. A doctoral dissertation from ​​Huazhong University of Science and Technology, (2005).

[3] Liu Yifan，computing research on the Three Gorges shiplift's long standoffs transfer mechanism [D]. ​​A Hehai University master's thesis, (2007).

[4] Zhang Guo-Xin, large concrete structures' SAPTIS instructions and users' manuals, 1994-(2005).

[5] GB50009-2001, Building Structures' Load Specifications [S].

[6] DL/T5057-1996, Specifications on Concrete Hydraulic Structures Design [S].

[7] DL 5077-1997, Specifications on Hydraulic structures' load design [S].

[8] GB50010, Specifications on concrete structures design [S].
