Numerical Simulation for Surface Displacement of Shield Tunnel Construction under Building Load

Abstract:

The tunnel construction causes deformation, even damage of the nearby buildings and other types of structures. Using 3d finite element method can simulate the process of shield tunneling construction. The paper studies the influence of different building load on the deformation of soil, when considering different excavation steps in the process of tunnel construction. The results show that the building load has important influence on the surface displacement during the construction of tunnel. With the advancement of excavation, sedimentation tank will move forward and become larger. By the influence of jacking force, the soil and rock in front of tunnel face moves forward and upward, thus forming the surface uplift.

• Periodical: Applied Mechanics and Materials (Volumes 405-408)
• Pages: 1350-1354
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.405-408.1350
• Online since: September 2013
• Authors: Hui Ting Zhan*, Hong Yuan, Jia Yu Wu, Yu Sen Yuan
• Keywords: 3D Finite Element Method, Building Load, Shield Tunnel, Surface Displacement

References

[1] Eric L and Barry N: Tunnelling and Underground Space Technology, Vol. 22 (2007), p.119.

[2] Rowe R K and Kack G J: Canadian Geotechnical Journal, Vol. 20 (1983), p.299.

[3] J. Wang and L. Miao: Modern Transportation Technology, Vol. 16 (2011), p.509 (In Chinese).

[4] M. FANG, C.Y. ZHOU and Z. LIU: Engineering Mechanics, Vol. 28 (2011), p.133 (In Chinese).

[5] B.G. He, T.Y. Chen and Y. Wang: ANSYS Civil Engineering Applications (China WaterPower Press, Beijing 2011) (In Chinese).

[6] Y.T. Zhang, J. Gao, J.L. Qiao and D.X. Qi: Soil Mechanics on Shield Tunneling (Tianjing University Press, Tianjing 2010) (In Chinese).

[7] X.M. Wang: ANSYS numerical analysis of engineering structures (China Communications Press, Beijing 2007) (In Chinese).
