Influence of Main Structural Dimension on the Shear Lag Effect of Box Girder Used in Cable-Stayed Bridge

Abstract:

Through simulating box girder with shell element, the influence of the top flangebottom flange and web thickness on the shear lag effect of box girder used in cable-stayed bridge was discussed on the background of Jianning bridge in Zhuzhou. Parameter analysis of the thickness change of the top flange, bottom flange and web on shear lag effect of box girder was based on analyzing and comparing the calculated results. The results show that the thickness change of the top flange, bottom flange and web have more influence on the shear lag effect of top flange than that of bottom flange; thickness increase of bottom flange and web can make the shear lag effect intensified obviously; and thickness change of web has the most significant influence on the shear lag effect among them for box girder with single box and three rooms used in cable-stayed bridges.

• Periodical: Applied Mechanics and Materials (Volumes 405-408)
• Pages: 1483-1488
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.405-408.1483
• Online since: September 2013
• Authors: Yu Ping Zhang*, Chuan Xi Li
• Keywords: Cable-Stayed Bridge, Finite Element Method (FEM), Parameter Analysis, Shear Lag Effect

References

[1] Shiyi Zhang; Xiaohua Deng; Wenzhou Wang. Shear Lag Effect of Box Thin-Walled Beam[M]Beijing: China Communications Press1998: 123～132(in Chinese).

[2] Qizhi Luo. Shear Lag Theory of Thin-Walled Box Girder Based on Energy Principles and Experimental Study PhD thesis, Hunan University2005. 11: 4～12(in Chinese).

[3] Guohui Cao; Zhi Fang; Xianyan Zhou; Mingjiao Zhu; Jie Deng. Geometrical Parameters Analysis of Thin-walled Box Girder Shear Lag[J] Foreign Highway Press 2003, 2(1), 39～41(in Chinese).

[4] Guohua Wen; C Xiangyun heng. The Influence of Prestressed Box Girder Transverse Normal Stress[J] Highway Press 1997, 11, 34~36(in Chinese).

[5] Jingjing Chen; Yongding Yao; Shehui; Xiang Yiqiang Tao. The Spatial Analysis on Tapered Three-span Prestressed Concrete Double-box Double Room Parallel Continuous Box Girder Bridge[J] Highway Traffic Techonology Press2003, 20(5), 36~39(in Chinese).

[6] Qizhi Luo; Yihong Lou; Jiabin Du; Wenhao Liu. The Shear Lag Effect of Variable Height Continuous Curved Box Girder[J]Railway Newspaper, 2007, 10(5), 79~84(in Chinese).

[7] Xialin Yang. Analysis of Space Stress on Double Box Single Bridge Box Girder[D] [Master thesis, Southwest Jiaotong University] Chengdu Southwest Jiaotong University, 2002(in Chinese).

DOI: 10.25103/jestr.074.16

[8] Xialin Yang; Jiehua Zhou. Parameters of the Bottom Thickness of Stayed Bridge[J] Lanzhou Railway Institute (Natural Science) 2003, 6, 84~87(in Chinese).

[9] Zhen Wan; Qiao Li. Analysis on Shear Lag Effect of Differet Cross-Section of Modern Cable-Stayed Bridge [J] Highway Traffic Techonology 2001, 2(2), 61~64(in Chinese).

[10] Shuguan Gong; Guilan Xie. Ansys Programming Operation Commands and Parameters[M], Machinery Industry Press, 2004(in Chinese).
