Digital Image Correlation Test System with Automatic Transmission for Quasi-Brittle Material

Abstract:

To realize the automatic transmission for present digital image capture test system, a new system which consists of laptop computer, camera, fixing device and mechanical testing machine was presented and designed. The Monitor software, which was developed using MATLAB to realize automatic transmission function for the system, includes slow and high speed. The general stage and key stage for quasi-brittle materials can be effectively captured by the software. With MATLAB, the digital image correlation software (DIC) was developed. In DIC the first image is used as the base image. The images are sorted by photographing time (or file name), and the listing file is generated. The grid is drawn on the base image to divide the area into ‘facets’, the size of which can be adjusted between 1pixel and 100 pixels. Based on fast Fourier transform and convolution algorithm, the image comparison is realized and the deformation of the material is calculated. The designed system is applied to the compression test of a concrete specimen, and the results show that the system realizes automatic transmission image capture, and calculates accurate displacement. The displacement distribution is uniform in linear elastic stage, and varies in yielding stage. This is mostly due to localized failure and displacement discontinuity.

• Periodical: Applied Mechanics and Materials (Volumes 405-408)
• Pages: 2515-2519
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.405-408.2515
• Online since: September 2013
• Authors: Hong Liang Yue*, Chun Hui Zhang, Yan Wang
• Keywords: Automatic Transmission, Digital Image Correlation (DIC), Fast Fourier Transform (FFT)

References

[1] L. Jing: Int J Rock Mech Min Sci Vol. 40 (2003), p.283.

[2] Tang C. A, Tham LG, Lee PKK, Yang TH, Li LC: Int J Rock Mech Min Sci Vol. 39 (2002), p.477.

[3] ZHANG Chunhui: Journal of China Coal Society Vol. 34 (2009), p.1460(In Chinese).

[4] ZHANG Chunhui, YU Yongjiang, ZHAO Quansheng: Rock and Soil Mechanics Vol. 30 (2009), p.2837(In Chinese).

[5] ZHANG Chunhui, ZHAO Quansheng, YU Yongjiang: Rock and Soil Mechanics Vol. 32 (2011), p.564(In Chinese).

[6] Lei Dong, Wang Kefeng, Tang Xiaobo, Shao Guojian: Journal of Underground Space and Engineering Vol. 7 (2011), p.1158(In Chinese).

[7] Xu X.H., Ma S.P., Xia M.F., et al: Theoretical and Applied Fracture Mechanics Vol. 42 (2004), p.131.

[8] GE Xiu-run, REN Jian-xi, PU Yi-bin, et al: Macro and Meso Testing Study on Damage Mechanics of Geotechnical Media (Science Press, China 2004).

[9] XIE Heping: Damage Mechanics of Rock and Concrete (University of Mining and Technology Press, China 1990).

[10] ZHAO Yang-sheng, MENG Qiaorong, KANG Tianhe, ZHANG Ning, XI Baoping: Chinese Journal of Rock Mechanics and Engineering Vol. 27 2008), p.28(In Chinese).

[11] Wu L. X., Liu S. J., Wu Y. H., et al: Int. J. Rock Mech. & Min. Sci. Vol. 39(2002), p.825.

[12] D. J. W H I T E, W. A. TAKE, M. D. BOLTON: Geotechnique Vol. 53(2003), p.619.

[13] MA Shaopeng: Chinese Journal of Rock Mechanics and Engineering Vol. 23 (2004), p.1410(In Chinese).
